RIEGLER Stainless steel pressure regulator, 1.4404, G 1/4, 0.5 - 8 bar
Type number: 571.14 B
EAN: 4047322101868
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Stainless steel pressure regulator, 1.4404, without secondary oil (non-reversible), incl. mano., G 1/4, control range 0.5 - 8 bar, PE max. 30 bar
Inlet pressure max. | 30 bar |
Housing | Stainless steel 1.4404 (AISI 316L) |
Sealing material | FKM |
Membrane | PTFE on NBR carrier |
Flow rate measurement | with P<sub>1</sub> = 8 bar, P<sub>2 </sub>= 6 bar and pressure drop Î"<sub>p</sub> ‰¤ 1 bar |
Medium temperature min. | -20 °C |
Medium temperature max. | 80 °C |
Ambient temperature min. | -20 °C |
Ambient temperature max. | 80 °C |
Thread | G 1/4 |
Flow rate | 1300 l/min |
Control range min. | 0.5 bar |
Control range max. | 8 bar |
A | 64 mm |
B | 160 mm |
C | 37 mm |
Class name | STAINLESS STEEL |
