RIEGLER Pressure gauge, robust design, G 1/2, 0 - 1.6 bar, Ø 100
Type number: 602
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Pressure gauge, robust design, Connection, rear, eccentric, G 1/2, Goods class 1.0, Measurement range 0-1.6 bar, Ø100
| Housing | CrNi steel |
| Medium temperature min. | -40 °C |
| Medium temperature max. | 80 °C |
| Ambient temperature min. | -40 °C |
| Ambient temperature max. | 60 °C |
| Type | 212.20 |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | Instrument flat glass |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 1.6 |
| Diameter | 100 mm |
| Graduation value in the bar range | 0.05 bar |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| Connection | G 1/2 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
| Quality class | 1 |
| Lower / Upper measuring range limit | Overpressure |
| Connection position | rear, eccentric |
| Class name | MAX |
| Process connection material | Copper alloy |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[102062] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 10 bar, Ø 100](/web/image/product.template/170034/image_128/%5B102062%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%2010%20bar%2C%20%C3%98%20100?unique=d0be2cb)
|
Type number: 606 |
61.40 € | |
![[102066] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 160 bar, Ø 100](/web/image/product.template/170038/image_128/%5B102066%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%20160%20bar%2C%20%C3%98%20100?unique=550b0e6)
|
Type number: 612 |
89.12 € | |
![[102063] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 16 bar, Ø 100](/web/image/product.template/170035/image_128/%5B102063%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%2016%20bar%2C%20%C3%98%20100?unique=375874b)
|
Type number: 607 |
61.40 € | |
![[102057] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 1 bar, Ø 100](/web/image/product.template/170029/image_128/%5B102057%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%201%20bar%2C%20%C3%98%20100?unique=a7ebae1)
|
Type number: 601 |
64.34 € | |
![[102067] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 250 bar, Ø 100](/web/image/product.template/170039/image_128/%5B102067%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%20250%20bar%2C%20%C3%98%20100?unique=08e05bd)
|
Type number: 613 |
89.12 € | |
![[102059] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 2.5 bar, Ø 100](/web/image/product.template/170031/image_128/%5B102059%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%202.5%20bar%2C%20%C3%98%20100?unique=344947a)
|
Type number: 603 |
64.34 € | |
![[102064] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 25 bar, Ø 100](/web/image/product.template/170036/image_128/%5B102064%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%2025%20bar%2C%20%C3%98%20100?unique=8640a99)
|
Type number: 608 |
61.40 € | |
![[102065] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 40 bar, Ø 100](/web/image/product.template/170037/image_128/%5B102065%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%2040%20bar%2C%20%C3%98%20100?unique=53cde0e)
|
Type number: 609 |
61.40 € | |
![[102060] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 4 bar, Ø 100](/web/image/product.template/170032/image_128/%5B102060%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%204%20bar%2C%20%C3%98%20100?unique=65be0b3)
|
Type number: 604 |
64.34 € | |
![[102061] RIEGLER Pressure gauge, robust design, G 1/2, 0 - 6 bar, Ø 100](/web/image/product.template/170033/image_128/%5B102061%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%200%20-%206%20bar%2C%20%C3%98%20100?unique=0f8e2ef)
|
Type number: 605 |
61.40 € | |
![[102056] RIEGLER Pressure gauge, robust design, G 1/2, -1 / 0 bar, Ø 100](/web/image/product.template/170028/image_128/%5B102056%5D%20RIEGLER%20Pressure%20gauge%2C%20robust%20design%2C%20G%201-2%2C%20-1%20-%200%20bar%2C%20%C3%98%20100?unique=7fc8437)
|
Type number: 600 |
64.34 € | |
