RIEGLER Glycerine pressure gauge, rear centric, G 1/4, -1 / +5 bar, Ø 63
Type number: 800/4-K
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Product no. :
102092EAN :
4047322118842Category :
Glycerine-Filled Pressure GaugesWeight :
0.16 kgGlycerine pressure gauge, plastic housing, double scale bar/psi, connection centric at rear, G 1/4, grade 2.5, measuring range -1/+5.0 bar, Ø 63
| Housing | Plastic, black (with front flange) |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Type | 113.13 |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | PMMA, welded to housing |
| Measuring range min. bar | -1 |
| Measuring range max. bar | 5 |
| Measuring range min. psi | -14.5 |
| Diameter | 63 mm |
| Graduation value in the bar range | 0.2 bar |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| Connection | G 1/4 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| Measuring range max. psi | 72 |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Quality class | 45414 |
| Lower / Upper measuring range limit | Vacuum/overpressure |
| Connection position | rear, centric |
| Class name | EASY |
| Process connection material | Copper alloy |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[102104] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 100 bar, Ø 63](/web/image/product.template/170076/image_128/%5B102104%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%20100%20bar%2C%20%C3%98%2063?unique=91fc548)
|
Type number: 812-K |
27.26 € | |
![[102099] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 10 bar, Ø 63](/web/image/product.template/170071/image_128/%5B102099%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%2010%20bar%2C%20%C3%98%2063?unique=c1e64bc)
|
Type number: 807-K |
27.26 € | |
![[102105] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 160 bar, Ø 63](/web/image/product.template/170077/image_128/%5B102105%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%20160%20bar%2C%20%C3%98%2063?unique=96ad731)
|
Type number: 813-K |
27.26 € | |
![[102095] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 1.6 bar, Ø 63](/web/image/product.template/170067/image_128/%5B102095%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%201.6%20bar%2C%20%C3%98%2063?unique=32eaf54)
|
Type number: 803-K |
27.26 € | |
![[102100] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 16 bar, Ø 63](/web/image/product.template/170072/image_128/%5B102100%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%2016%20bar%2C%20%C3%98%2063?unique=ed06225)
|
Type number: 808-K |
27.26 € | |
![[102094] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 1 bar, Ø 63](/web/image/product.template/170066/image_128/%5B102094%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%201%20bar%2C%20%C3%98%2063?unique=9574199)
|
Type number: 802-K |
27.26 € | |
![[102106] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 250 bar, Ø 63](/web/image/product.template/170078/image_128/%5B102106%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%20250%20bar%2C%20%C3%98%2063?unique=23ec504)
|
Type number: 814-K |
27.26 € | |
![[102096] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 2.5 bar, Ø 63](/web/image/product.template/170068/image_128/%5B102096%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%202.5%20bar%2C%20%C3%98%2063?unique=d36c606)
|
Type number: 804-K |
27.26 € | |
![[102101] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 25 bar, Ø 63](/web/image/product.template/170073/image_128/%5B102101%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%2025%20bar%2C%20%C3%98%2063?unique=5ff03a0)
|
Type number: 809-K |
27.26 € | |
![[102107] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 400 bar, Ø 63](/web/image/product.template/170079/image_128/%5B102107%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%20400%20bar%2C%20%C3%98%2063?unique=876826d)
|
Type number: 815-K |
27.26 € | |
![[102102] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 40 bar, Ø 63](/web/image/product.template/170074/image_128/%5B102102%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%2040%20bar%2C%20%C3%98%2063?unique=35690ba)
|
Type number: 810-K |
27.26 € | |
![[102097] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 4 bar, Ø 63](/web/image/product.template/170069/image_128/%5B102097%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%204%20bar%2C%20%C3%98%2063?unique=1bbde1c)
|
Type number: 805-K |
27.26 € | |
![[102103] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 60 bar, Ø 63](/web/image/product.template/170075/image_128/%5B102103%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%2060%20bar%2C%20%C3%98%2063?unique=f11cc57)
|
Type number: 811-K |
25.37 € | |
![[102098] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, 0 - 6 bar, Ø 63](/web/image/product.template/170070/image_128/%5B102098%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%200%20-%206%20bar%2C%20%C3%98%2063?unique=dc66400)
|
Type number: 806-K |
27.26 € | |
![[102089] RIEGLER Glycerine pressure gauge, rear centric, G 1/4, -1 / +0.6 bar, Ø63](/web/image/product.template/170061/image_128/%5B102089%5D%20RIEGLER%20Glycerine%20pressure%20gauge%2C%20rear%20centric%2C%20G%201-4%2C%20-1%20-%20%2B0.6%20bar%2C%20%C3%9863?unique=0e13ca4)
|
