RIEGLER 3/2-way solenoid valve brass, NC, 230/50 V AC, 50 Hz, FKM, G 1/8
Type number: 107.11
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
3/2-way solenoid valve brass, NC, 230/50 V AC, 50 Hz, Sealing material FKM, Medium temp. -10 °C to 100 °C, G 1/8, PN 0 - 15 bar
| Housing | Brass |
| Sealing material | FPM |
| Protection class | IP 65 (when using the cable plug) |
| Electrical connection | Cable plug, 180° rotatable, PG7 to 43650 |
| Operating pressure min. | 0 bar |
| Max. operating pressure | 15 bar |
| Medium temperature min. | -10 °C |
| Medium temperature max. | 100 °C |
| Ambient temperature min. | -10 °C |
| Ambient temperature max. | 60 °C |
| Area of application | Compressed air and neutral, non-toxic gases, water, oil |
| Interior parts | Stainless steel |
| Thread | G 1/8 |
| DN | 45323 |
| Function | Interchangeable magnetic heads direct/alternating current |
| Tension | 230/50 V AC, 50 Hz |
| A | 58 mm |
| B | 33 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | none |
| Class name | MAX |
