RIEGLER Vacuum pressure switch, Special die casting,G 1/4,-0.85/-0.15 bar

Type number: DS 5912

67.40 € 67.4 EUR 67.40 € VAT Included

84.53 € VAT Included

Brand

This combination does not exist.

Add to Cart

from 110 € free shipping Details shipping costs

Riegler

RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.

Product no. :

103039

EAN :

4047322212205

Category :

Mechanically Operated

Weight :

0.29 kg

Description
Specifications

Vacuum pressure switch, Electrical M12x1, Temp. -20 °C to 80 °C, G 1/4, Setting range -0.85 / -0.15 bar, max. 48 V AC / 24 V DC

Temperature range min.	-20 °C
Temperature range max.	80 °C
Housing	Special casting
Membrane	NBR
Protection class	IP 65 (DIN 43650), IP 67 (M12x1)
Area of application	Compressed air applications
Switching voltage	max. 48 V AC / 24 V DC
Switching frequency	1Hz
Setting range	-0.85 / -0.15 bar
A	48 mm
B	28 mm
REACH SVHC1 Substance Name	Lead
CAS No. SVHC 1	7439-92-1
Connection	G 1/4
RoHS material information	RoHS compliant
RoHS Directive	2011/65/EU, 2015/863/EU, 2018/741/EU
RoHS Article of the Directive	Article 4, paragraph 1, Annex 3
Share of SVHC substance in % for RoHS	0.04
Exception	6c
REACH Info	contains SVHC substance
Share of SVHC SCIP	>= 1.0% w/w and < 10.0% w/w
Proportion of SVHC substance in SCIP	>= 0.1 % in w/w
Material identification	CW614N
Class name	PLUS
Inductive load	max. 1 A
resistive load	max. 4 A / 3 A
