RIEGLER Vacuum switch, Polycarbonate, Plug M8, 4-pole, G 1/8 ET, M5 IT
Type number: VS 27
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Vacuum switch, polycarbonate, M8 plug, 4-pin, G 1/8 male, M5 female, M8x1 male, temp. 0 °C to 50 °C, 10.8 - 30 V DC
| Temperature range min. | 0 °C |
| Temperature range max. | 50 °C |
| Medium | non-aggressive gases and dry, oil-free air |
| Housing | Polycarbonates |
| Electrical connection | M8 plug, 4-pin |
| Operating voltage | 10.8 - 30 V DC |
| Hysteresis | adjustable: 3 % to 25 % of the set value |
| Output signal | analog 1 - 5 V |
| Switching capacity | 125 mA |
| Switching function | switching against + |
| Measuring medium connection | G 1/8 AG and M5 IG |
| Power consumption | 30 mA |
| Measuring range min. bar | -1 |
| Measuring range max. bar | 0 |
| L | 44 mm |
| L1 | 62 mm |
| G 1 | G 1/8 AG |
| G 2 | M5 IG |
| G 3 | M8x1 AG |
| Class name | PLUS |
