RIEGLER Vacuum switch, Polycarbonate, Plug M8, 4-pole, G 1/8 ET, M5 IT
Type number: VS 27
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Vacuum switches made of polycarbonate - type VS 27
The RIEGLER vacuum switch, plug M8, 4-pin, G 1/8 AG, M5 IG, M8x1 AG generates or uses vacuum for handling and automation tasks. The housing is made of polycarbonate. The temperature range is between 0 °C and 50 °C. Suitable for non-aggressive gases and dry, oil-free air. Operating voltage 10.8 - 30 V DC. Reliable vacuum technology.
Field of application
Typical areas of application: Robotics and packaging technology.
| Temperature range min. | 0 °C |
| Temperature range max. | 50 °C |
| Medium | non-aggressive gases and dry, oil-free air |
| Housing | Polycarbonates |
| Electrical connection | M8 plug, 4-pin |
| Operating voltage | 10.8 - 30 V DC |
| Hysteresis | adjustable: 3 % to 25 % of the set value |
| Output signal | analog 1 - 5 V |
| Switching capacity | 125 mA |
| Switching function | switching against + |
| Measuring medium connection | G 1/8 AG and M5 IG |
| Power consumption | 30 mA |
| Measuring range min. bar | -1 |
| Measuring range max. bar | 0 |
| L | 44 mm |
| L1 | 62 mm |
| G 1 | G 1/8 AG |
| G 2 | M5 IG |
| G 3 | M8x1 AG |
| Class name | PLUS |
