5/2-way valve, electropneumatic, monostable, G 1/4, 12 V DC
Type number: MS24VAC-1
EAN: 4047322773966
Product no. :
145881Category :
Valves Electropneumatically Operated5/2-way valve, electropneumatic, monostable, G 1/4, 12 V DC, p = 2.5 ... 10 bar, aluminum
| Medium | Filtered compressed air with or without lubrication. If lubricated, then continuous. |
| Sealing material | NBR |
| Series | Valves Series 70 |
| Operating pressure min. | 2.5 bar |
| Max. operating pressure | 10 bar |
| Medium temperature min. | -10 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -10 °C |
| Ambient temperature max. | 50 °C |
| Manual override | resting |
| DN | 45419 |
| Actuation | monostable |
| Symbol | 35 |
| Tension | 12 V DC |
| Connection | G 1/4 |
| Durchfluss_1 | 750 Nl/min |
| Durchfluss_2 | 1100 Nl/min |
| Class name | PLUS |
| Function | 45327 |
| Flow rate measurement 1 | Flow rate at 6 bar and Δp 0.5 bar |
| Flow rate measurement 2 | Flow rate at 6 bar and Δp 1.0 bar |
