Fine pressure gauge, G 1/2 radial bottom, 0 - 400.0 bar, Ø 160

https://www.filcom-technik.de/web/image/product.template/276082/image_1920?unique=df9d998

Type number: 435.7040-NBR

EAN: 4047322699877

270.87 € 270.87 EUR 270.87 € VAT Included

350.19 € VAT Included

    This combination does not exist.

    from 110 € free shipping Details shipping costs
    Contact Us
    Product no. :
    199330
    Category :
    Precision Pressure Gauges

    Fine pressure gauge, radial bottom connection, G 1/2, grade 0.6, scale graduation. 2.000, measuring range 0 - 400.0 bar, Ø 160
    Housing CrNi steel
    Medium temperature max. 60 °C
    Ambient temperature min. -20 °C
    Ambient temperature max. 60 °C
    Measuring element CrNi steel
    Pointer movement Brass
    Measuring range min. bar 0
    Measuring range max. bar 400
    Diameter 160 mm
    Graduation value in the bar range 2 bar
    Connection G 1/2
    Quality class 0.6
    Lower / Upper measuring range limit Overpressure
    Ring CrNi steel
    Connection position radial bottom
    Class name PLUS
    Viewing window Plastic (PMMA)
    Process connection Brass, radial bottom, G1/2B - SW22 (EN 837-1/7.3)
    Process connection material Brass
