Condor Pressure Switch MDR 53/16 6-16 bar G 1/2"
Condor MDR 53/16 bar
Pressure switch compressor / pressure switch pump
Applications: Compressed air technology and water technology
Condor-Werke
The Condor Group is a global leader in manufacturing components and system solutions for the control and regulation of pressure and level. With their extensive range, they cater to various industries and applications such as industrial automation and water and wastewater technology.
Condor control pressure switch MDR 53/16 bar 213086
1 changeover contact - SPDT
Pressure range 6.00 - 16.00 bar
Large connection space
High switching accuracy
Pressure adjustment possible without tools
According to EN 60947
CSA approval optional
Pressure switch type: HAA BAAA xxxA160 XAA XXX see under Documents.
For the cable glands required for retrofitting and the cover, see "Accessories".
Application areas:Compressed air technology
Water technology
| Protection class | IP 54 |
| Motor switching capacity (kW) | 4.0 kW |
| Max. media temperature (°C) | 80 |
| Current version | Alternating current |
| Type of construction | Electro-mechanical |
| Tension | ≤ 250 V |
| Contact function | Changer |
| Rated frequency | 50 Hz / 60 Hz |
Accessoires and suitable extensions
| Product | Price | ||
|---|---|---|---|
![[230045] Condor Mounting bracket](/web/image/product.template/95986/image_128/%5B230045%5D%20Condor%20Mounting%20bracket?unique=9fb4297)
|
Condor mounting bracket for Condor pressure switch MDR 5 and MDR 53 |
14.16 € | |
![[269496] Condor Grommet WN M20 for cable gland MDR 5](/web/image/product.template/95980/image_128/%5B269496%5D%20Condor%20Grommet%20WN%20M20%20for%20cable%20gland%20MDR%205?unique=9fb4297)
|
Condor choke nipple for Condor cable glands for Condor pressure switches MDR 5 and MDR 53 |
5.24 € | |
![[269502] Condor Screw plug M20](/web/image/product.template/95981/image_128/%5B269502%5D%20Condor%20Screw%20plug%20M20?unique=4638de6)
|
Condor screw plug M 20 for Condor pressure switch MDR 5 and MDR 53 |
2.86 € | |
![[269519] Condor Cable gland M20 L with strain relief, clamping range 10-14 mm](/web/image/product.template/95984/image_128/%5B269519%5D%20Condor%20Cable%20gland%20M20%20L%20with%20strain%20relief%2C%20clamping%20range%2010-14%20mm?unique=43e009d)
|
Condor cable gland for Condor pressure switch MDR 5 and MDR 53 |
12.50 € | |
![[269526] Condor Cable gland M20 LK with strain relief and cable support, clamping range 10-14 mm](/web/image/product.template/95985/image_128/%5B269526%5D%20Condor%20Cable%20gland%20M20%20LK%20with%20strain%20relief%20and%20cable%20support%2C%20clamping%20range%2010-14%20mm?unique=9549cf7)
|
Condor cable gland for Condor pressure switch MDR 5 and MDR 53 |
12.85 € | |
![[269533] Condor Cable gland M20 Z with strain relief, clamping range 6-12 mm](/web/image/product.template/95982/image_128/%5B269533%5D%20Condor%20Cable%20gland%20M20%20Z%20with%20strain%20relief%2C%20clamping%20range%206-12%20mm?unique=a20e002)
|
Condor cable gland for Condor pressure switch MDR 5 and MDR 53 |
12.50 € | |
![[269540] Condor Cable gland M20 ZK with strain relief and cable support, clamping range 6-12 mm](/web/image/product.template/95983/image_128/%5B269540%5D%20Condor%20Cable%20gland%20M20%20ZK%20with%20strain%20relief%20and%20cable%20support%2C%20clamping%20range%206-12%20mm?unique=b4f2e94)
|
Condor cable gland for Condor pressure switch MDR 5 and MDR 53 |
12.85 € | |
Maintenance, wear and spare parts
| Product | Price | ||
|---|---|---|---|
![[230052] Condor Cover H5 without On/Off push buttons for MDR 5](/web/image/product.template/95987/image_128/%5B230052%5D%20Condor%20Cover%20H5%20without%20On-Off%20push%20buttons%20for%20MDR%205?unique=e6d34e3)
|
Condor cover for Condor control pressure switch MDR 5 and MDR 53 |
18.56 € | |
