Wortmann Oil-water-seperators model drukomat 30
Drukomat 30 oil water separator, new unit incl. one filter set.
up to 30 m³/min compressor capacity.
Professional condensate treatment with an oil separator / water separator to protect the compressed air system or compressor. The Wortmann oil-water separator reliably separates oily condensate and ensures oil-free compressed air.
Wortmann
For over 35 years, Wortmann has been providing practical system solutions for compressed air treatment.
Wortmann Drukomat 30 oil water separator 3004, incl. a filter set.
The Drukomat 30 reliably de-oils the condensate produced through a combination of deflection and settling chamber, as well as a series connection of coalescence and activated carbon filters directly at the point of origin.
The treated condensate can be discharged directly into the sewer system as purified water.
Filtration:
Pre-filter: 1 x 0.3
Water side: 2 x 3.8 kg
Air side: 1 x 1.5 kg
For further technical data, see "Downloads" below.
| Max. Compressor capacity (m³/min) | 30 |
| Container volume (litres) | 230 |
| Height (mm) | 1.160 |
| Width (mm) | 850 |
| Depth (mm) | 520 |
| Condensate inlet connection | 4x 1/2" thread with hose nozzle |
| Water drain connection | 1" thread with hose nozzle |
| Oil drain connection | 1" thread with hose nozzle |
| Pre-filter (kg) | 4x 0,3 |
| Filtering activated carbon water (kg) | 1x 3,8 |
| Activated carbon air filtration (kg) | 1x 1,5 |
Maintenance, wear and spare parts
| Product | Price | ||
|---|---|---|---|
![[WO-3067] Wortmann Replacement filterset for Drukomat 30](/web/image/product.template/121742/image_128/%5BWO-3067%5D%20Wortmann%20Replacement%20filterset%20for%20Drukomat%2030?unique=23c5832)
|
The original in top quality Activated carbon replacement filter complete set for Drukomat 30 High-quality replacement filters for oil separators and water separators. |
523.60 € | |
