RIEGLER Glycerine pressure gauge, triangle front ring, G 1/2, 0 - 25 bar
Type number: 1028
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Product no. :
102300EAN :
4047322012263Category :
Glycerine-Filled Pressure GaugesWeight :
1.30 kgGlycerine pressure gauge, bracket fastening, triangle front ring, Connection, rear, eccentric, G 1/2, Meas. range 0 - 25 bar, Ø100
| Housing | Pressed brass |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Type | 213.40 |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | Acrylic glass |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 25 |
| Diameter | 100 mm |
| Graduation value in the bar range | 0.5 bar |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| Connection | G 1/2 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Quality class | 1 |
| Lower / Upper measuring range limit | Overpressure |
| Connection position | rear, eccentric |
| Class name | MAX |
| Process connection material | Copper alloy |
