RIEGLER 3/2-way mini solenoid valve directly controlled, NO, 12 VDC cable
Type number: MV 1062.2
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Product no. :
106648EAN :
4047322156561Category :
Valves Electropneumatically OperatedWeight :
0.04 kg3/2-way mini solenoid valve direct operated, NW 1.5 mm, NO, 12 VDC, cable (30 cm), pressure 0 - 5 bar, temp. -10 °C to 50 °C
| Temperature range min. | -10 °C |
| Temperature range max. | 50 °C |
| Medium | filtered, unlubricated compressed air |
| Sealing material | NBR, stainless steel |
| Power consumption | 2,5 W |
| Operating pressure min. | 0 bar |
| Max. operating pressure | 5 bar |
| Flow rate | QN (p1 = 6 bar, Î "p = 1 bar) = 50 Nl/min |
| Material | Plastic |
| Switching frequency | max. 2400/min |
| Opening and closing times | 10 - 12 ms (depending on pressure) |
| Coil power | 2.5 W |
| Manual override | groping |
| Height | 42 mm |
| Width | 15 mm |
| Function | 3/2 NO |
| Actuation | electric with manual override |
| Type of construction | directly controlled |
| Application | Mounting on base plate |
| Tension | 12 V DC |
| Nominal Ø | 1.5 mm |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| Connection | Cable (30 cm) |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| Manual override plate | black |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Class name | PLUS |
