RIEGLER Knurled nut, M18x1.5, for hose 9/12 mm, PP
Type number: 160.04
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Knurled nut for pneumatic installation, M18x1.5 - Type 160.04
The RIEGLER knurled nut, M18x1.5, for hose 9/12 mm, PP connects compressed air hoses and pipes quickly and securely by simply screwing them in. Connection thread M18x1.5 - suitable for common industry standards. Simple assembly and disassembly for flexible line routing.
Field of application
Typical areas of application: Compressed air installations and pneumatic systems.
| Screw fitting body | Polyamide (PA) |
| Clamping ring | Polypropylene (PP) |
| Knurled nut | Polypropylene (PP) |
| Max. operating pressure at 20 °C | 10 bar |
| Max. operating pressure at 60 °C | 1 bar |
| Thread | M18x1.5 |
| for hose | 9/12 mm |
| L1 | 20 mm |
| Class name | FLEX |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[110820] RIEGLER Knurled nut, M10x1, for hose 4/6 mm, PP](/web/image/product.template/181750/image_128/%5B110820%5D%20RIEGLER%20Knurled%20nut%2C%20M10x1%2C%20for%20hose%204-6%20mm%2C%20PP?unique=72f9ba3)
|
Type number: 160.01 |
0.43 € | |
![[110821] RIEGLER Knurled nut, M14x1.5, for hose 6/8 mm, PP](/web/image/product.template/181751/image_128/%5B110821%5D%20RIEGLER%20Knurled%20nut%2C%20M14x1.5%2C%20for%20hose%206-8%20mm%2C%20PP?unique=b71295d)
|
Type number: 160.02 |
0.51 € | |
![[110822] RIEGLER Knurled nut, M16x1.5, for hose 8/10 mm, PP](/web/image/product.template/181752/image_128/%5B110822%5D%20RIEGLER%20Knurled%20nut%2C%20M16x1.5%2C%20for%20hose%208-10%20mm%2C%20PP?unique=0de92d7)
|
Type number: 160.03 |
0.62 € | |
