RIEGLER Standard pressure gauge »pressure line« G 1/8, 0 - 4 bar/56 psi
Type number: 110.44-KDE
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Standardmano. »pressure line«, Kunststoffgeh., Anschluss hinten zentr., G 1/8, Güteklasse 2,5, Messber. 0 - 4,0 bar/56 psi, Ø 40
| Housing | Plastic |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | Plastic |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 4 |
| Diameter | 40 mm |
| Graduation value in the bar range | 0.2 bar |
| Execution | Bourdon tube pressure gauge |
| Connection | G 1/8 |
| Quality class | 45414 |
| Lower / Upper measuring range limit | Overpressure |
| Connection position | rear, centric |
| Class name | EASY |
| Process connection material | Copper alloy |
