RIEGLER Glycerine pressure gauge »pressure line« G 1/2, 0-400bar/6000 psi

Price:

36.60 €

English (US)
  2. Shop
  3. Glycerine-Filled Pressure Gauges
  4. RIEGLER Glycerine pressure gauge »pressure line« G 1/2, 0-400bar/6000 psi
RIEGLER Glycerine pressure gauge »pressure line« G 1/2, 0-25 bar/360 psi
RIEGLER Glycerine pressure gauge »pressure line« G 1/2, 0-25 bar/360 psi
34.94 € 34.94 €
RIEGLER Glycerine pressure gauge »pressure line« G 1/2, 0-40 bar/600 psi
RIEGLER Glycerine pressure gauge »pressure line« G 1/2, 0-40 bar/600 psi
34.94 € 34.94 €

RIEGLER Glycerine pressure gauge »pressure line« G 1/2, 0-400bar/6000 psi

https://www.filcom-technik.de/web/image/product.template/201057/image_1920?unique=2ccbb2d

Type number: 735-CDE

36.60 € 36.6 EUR 36.60 € VAT Included

42.73 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

116324

EAN :

4047322176989

Category :

Glycerine-Filled Pressure Gauges

Weight :

0.72 kg

Glycerin mano. "pressure line", stainless steel housing, radial bottom connection, G 1/2, grade 1.6, measuring range 0-400.0 bar/6000 psi, Ø100

Housing Stainless steel 1.4301
Medium temperature min. -20 °C
Medium temperature max. 60 °C
Ambient temperature min. -20 °C
Ambient temperature max. 60 °C
Measuring element Brass
Pointer movement Brass
Viewing window Glass
Measuring range min. bar 0
Measuring range max. bar 400
Diameter 100 mm
Graduation value in the bar range 10 bar
Execution Bourdon tube pressure gauge with glycerine filling
Connection G 1/2
Quality class 45444
Connection position radial bottom
Class name EASY
Process connection material Copper alloy
