RIEGLER Angle seat valve, Piston drive, NC, Bronze, G 1 1/2
Type number: 3362.08
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Angle seat valve, piston actuator without NAMUR interface bronze, medium temp. -10°C to 180°C, G 1 1/2, max. operating pressure diff. 11 bar
| Housing | Bronze |
| Sealing material | PTFE |
| Medium temperature min. | -10 °C |
| Medium temperature max. | 180 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 70 °C |
| Control pressure min. | 4 bar |
| Control pressure max. | 8 bar |
| Pilot air connection | G 1/8 |
| Spindle | Stainless steel |
| Differential pressure min. | 0 bar |
| max. differential pressure (bar) | 16 bar |
| Permissible static pressure max. | 16 bar |
| Temperature of control medium max. | 60 °C |
| Control head | Polyamide (glass fiber reinforced) |
| Connectors | Stainless steel |
| Thread | G 1 1/2 |
| Operating pressure difference max. | 11 bar |
| Function | NC |
| A | 270 mm |
| C | 264 mm |
| F | 120 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| Piston | PBT + GF 30 % |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
| Class name | FLEX |
| REACH SVHC2 Substance Name | Octamethylcyclotetrasiloxane (D4) |
| REACH SVHC3 Substance Name | Decamethylcyclopentasiloxane (D5) |
| REACH SVHC4 Substance Name | Dodecamethylcyclohexasiloxane (D6) |
