RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 2
Type number: 1085 H
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
3-way ball valve, MS nickel-plated, bottom connection, L-bore, Rp 2, DN 50, operating temperature -15 °C to 120 °C, PN max. 10 bar
| Housing | Nickel-plated brass (CW617N) |
| Ball | Nickel-plated brass (CW617N) |
| Ball seal | PTFE |
| Spindle seal | PTFE / FKM |
| Hand lever | Steel, with plastic coating |
| Operating temperature min. | -15 °C |
| Operating temperature max. | 120 °C |
| Thread | Rp 2 |
| DN | 50 |
| SW | 70 mm |
| PN | 10 bar |
| Thread standard | Rp thread according to ISO 7-1 |
| A | 170 mm |
| B | 101 mm |
| L | 130 mm |
| E | 25.7 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| H1 | 67 mm |
| H2 | 73 mm |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | none |
| Thread material | Brass bright |
| Class name | PLUS |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[136330] RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 1](/web/image/product.template/207538/image_128/%5B136330%5D%20RIEGLER%203-way%20ball%20valve%2C%20nickel-plated%20brass%2C%20L-hole%2C%20Rp%201?unique=73dbdd4)
|
Type number: 1085 E |
79.65 € | |
![[136332] RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 1 1/2](/web/image/product.template/207540/image_128/%5B136332%5D%20RIEGLER%203-way%20ball%20valve%2C%20nickel-plated%20brass%2C%20L-hole%2C%20Rp%201%201-2?unique=a58e3b0)
|
Type number: 1085 G |
166.49 € | |
![[136331] RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 1 1/4](/web/image/product.template/207539/image_128/%5B136331%5D%20RIEGLER%203-way%20ball%20valve%2C%20nickel-plated%20brass%2C%20L-hole%2C%20Rp%201%201-4?unique=660928f)
|
Type number: 1085 F |
123.36 € | |
![[136328] RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 1/2](/web/image/product.template/207536/image_128/%5B136328%5D%20RIEGLER%203-way%20ball%20valve%2C%20nickel-plated%20brass%2C%20L-hole%2C%20Rp%201-2?unique=a15bb91)
|
Type number: 1085 C |
44.07 € | |
![[136326] RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 1/4](/web/image/product.template/207534/image_128/%5B136326%5D%20RIEGLER%203-way%20ball%20valve%2C%20nickel-plated%20brass%2C%20L-hole%2C%20Rp%201-4?unique=9bb8df1)
|
Type number: 1085 A |
38.79 € | |
![[136329] RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 3/4](/web/image/product.template/207537/image_128/%5B136329%5D%20RIEGLER%203-way%20ball%20valve%2C%20nickel-plated%20brass%2C%20L-hole%2C%20Rp%203-4?unique=f0ca4c8)
|
Type number: 1085 D |
62.27 € | |
![[136327] RIEGLER 3-way ball valve, nickel-plated brass, L-hole, Rp 3/8](/web/image/product.template/207535/image_128/%5B136327%5D%20RIEGLER%203-way%20ball%20valve%2C%20nickel-plated%20brass%2C%20L-hole%2C%20Rp%203-8?unique=e6c6a99)
|
Type number: 1085 B |
38.79 € | |
