RIEGLER Battery regulator "SYNTESI", BG1, G 1/8, 0...12 bar, o. Mano.
Type number: 5611R261
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Battery regulator "SYNTESI", BG 1, G 1/8, p1 = max. 15 bar, p2 = 0 ? 12 bar, T = -10 ? 50 °C, without pressure gauge
| Inlet pressure max. | 15 bar |
| Temperature range min. | -10 °C |
| Temperature range max. | 50 °C |
| Medium | Compressed air or other neutral gases |
| Housing | Technopolymer |
| Sealing material | NBR |
| Membrane | NBR 60 Shore (hardness) with polyester fabric insert |
| Control range min. | 0 bar |
| Control range max. | 12 bar |
| BG | 1 |
| Input connection | G 1/8 |
| Output connection | G 1/8 |
| A | 42 mm |
| B | 102 mm |
| D | 51.5 mm |
| Flow_1 | 330 Nl/min |
| Flow_2 | 500 Nl/min |
| Flow rate measurement 1 | at P<sub>1</sub> = 10 bar, P<sub>2</sub> = 6.3 bar and pressure drop Î"<sub>p</sub> = 0.5 bar |
| Flow rate measurement 2 | at P<sub>1</sub> = 10 bar, P<sub>2</sub> = 6.3 bar and pressure drop Î"<sub>p</sub> = 1 bar |
| Class name | PLUS |
| Thread on front and back | G 1/8 |
| Series | Syntesi |
| Spring cover | Technopolymer |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[139983] RIEGLER Battery regulator "SYNTESI", BG1, G 1/4, 0...12 bar, o. Mano.](/web/image/product.template/277629/image_128/%5B139983%5D%20RIEGLER%20Battery%20regulator%20%22SYNTESI%22%2C%20BG1%2C%20G%201-4%2C%200--.12%20bar%2C%20o.%20Mano.?unique=770ab19)
|
