Filter+oil filter "SYNTESI", BG 2, G 3/8, 5 µm + 0.01 µm, RA + RMSA
Type number: 213-KD
EAN: 4047322768726
Filter + oil filter "SYNTESI", BG 2, G 3/8, 5 µm + 0.01 µm, p1 = max. 10 bar, RA fully automatic + RMSA semi-automatic, T = -10 ... 50 °C
| Inlet pressure max. | 10 bar |
| Temperature range min. | -10 °C |
| Temperature range max. | 50 °C |
| Medium | Compressed air or other neutral gases |
| Housing | Technopolymer |
| Sealing material | NBR |
| Container | Technopolymer |
| BG | 2 |
| Input connection | G 3/8 |
| Output connection | |
| A | 121 mm |
| B | 182 mm |
| Class name | PLUS |
| Filterfeinheit des Ölfilters | 0.01 µm |
| Filterfeinheit des Filters | 5 µm |
| Air purity class at the outlet according to | 37438 |
| Thread on front and back | G 1/4 |
| Kondensatablass des Filters | RA fully automatic |
| Kondensatablass des Ölfilters | |
| Series | Syntesi |
| F | 38.2 mm |
| Recommended flow rate at 6.3 bar | 1050 Nl/min |
