Type number: 39.015GE

EAN: 4047322773638

61.27 € 61.27 EUR 61.27 € VAT Included

79.22 € VAT Included

    This combination does not exist.

    from 110 € free shipping Details shipping costs
    Contact Us
    Product no. :
    145848
    Category :
    Valves Electropneumatically Operated

    3/2-way valve, electropneumatic, monostable, G 1/8, NO, 12 V DC, p = 2.5 ... 10 bar, aluminum
    Medium Filtered compressed air with or without lubrication. If lubricated, then continuous.
    Sealing material NBR
    Series Valves Series 70
    Operating pressure min. 2.5 bar
    Max. operating pressure 10 bar
    Medium temperature min. -10 °C
    Medium temperature max. 60 °C
    Ambient temperature min. -10 °C
    Ambient temperature max. 50 °C
    Manual override resting
    DN 5
    Function 3/2 NO
    Actuation monostable
    Symbol 32
    Tension 12 V DC
    Connection G 1/8
    Durchfluss_1 400 Nl/min
    Durchfluss_2 550 Nl/min
    Class name PLUS
    Flow rate measurement 1 Flow rate at 6 bar and Δp 0.5 bar
    Flow rate measurement 2 Flow rate at 6 bar and Δp 1.0 bar
