RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NO, 110 V AC

Price:

79.21 €

English (US)
  2. Shop
  3. Valves Electropneumatically Operated
  4. RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NO, 110 V AC
RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NC, 24 V AC
RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NC, 24 V AC
79.21 € 79.21 €
RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NO, 24 V AC
RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NO, 24 V AC
79.21 € 79.21 €

RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NO, 110 V AC

https://www.filcom-technik.de/web/image/product.template/275801/image_1920?unique=489e05b

Type number: 517.32.14.NO.110A

79.21 € 79.21000000000001 EUR 79.21 € VAT Included

92.45 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

145877

EAN :

4047322773928

Category :

Valves Electropneumatically Operated

Weight :

0.29 kg

3/2-way valve, electropneumatic, monostable, G 1/4, NO, 110 V AC, 50/60 Hz, p = 2.5 ? 10 bar, aluminum

Medium Filtered compressed air with or without lubrication. If lubricated, then continuous.
Sealing material NBR
Series Valves Series 70
Operating pressure min. 2.5 bar
Max. operating pressure 10 bar
Medium temperature min. -10 °C
Medium temperature max. 60 °C
Ambient temperature min. -10 °C
Ambient temperature max. 50 °C
Manual override resting
DN 45419
Function 3/2 NO
Actuation monostable
Symbol 32
Connection G 1/4
Flow 1 750 Nl/min
Flow 2 1100 Nl/min
Class name PLUS
Tension 110 V, 50/60 Hz
Flow rate measurement 1 Flow rate at 6 bar and Δp 0.5 bar
Flow rate measurement 2 Flow rate at 6 bar and Δp 1.0 bar

Maintenance, wear and spare parts

Product Price
[145692] RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/4, NO

Type number: 7020020400

 67.88 €
[117313] RIEGLER Device plug, 22 mm, type B

Type number: 1920.9P

 1.48 €
[118629] RIEGLER Solenoid coil, 22 mm x Ø 8 mm, 110 V AC, 50/60 Hz, 3.5 VA

Type number: 400-514-07

 9.87 €
