RIEGLER Piston rod sl. Cyl. ZRL1S, Ø 40, stroke 250, standard, slow speed
Typennummer: ZRL1S.400250.LL
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Constant pressure regulator incl. pressure gauge, BG 5, G 1 1/2, PE max. 40 bar, medium temperature max. 60 °C, control range 0.2 - 6 bar
| Sealing material | Oil-resistant plastic (NBR) |
| Medium | Filtered compressed air (max. 50 µm) |
| Temperature range max. | 55 °C |
| Screws | Steel 10.9 galvanized |
| Temperature range min. | -10 °C |
| Working pressure min. | 0.5 bar |
| Stroke | 250 mm |
| Air connection | 3-fold on both sides |
| Piston Ø | 40 mm |
| Working pressure max. | 8 bar |
| Piston caps and sliding parts | abrasion-resistant plastic |
| Installation position | any |
| Function | double-acting |
| Sealing tapes | Stainless steel |
| Connection | G 1/4 |
| Damping | with adjustable damping |
| Magnet | with magnet |
| Class name | PLUS |
| Load clutch | Rigid |
