Filtration Group Low pressure filter Pi 2728-069

Price:

488.88 €

English (US)
  2. Shop
  3. Filtration Group Low Pressure Filter
  4. Filtration Group Low pressure filter Pi 2728-069
Filtration Group Low pressure filter Pi 2728-068
Filtration Group Low pressure filter Pi 2728-068
419.59 € 419.59 €
Filtration Group PI 3615-013 Low pressure filter
Filtration Group PI 3615-013 Low pressure filter
557.18 € 557.18 €

Filtration Group Low pressure filter Pi 2728-069

https://www.filcom-technik.de/web/image/product.template/55472/image_1920?unique=e7a56e7

Low-pressure filter Pi 2728-69
Nominal size 25 l/min
Includes:
- Electrical maintenance indicator

488.88 € 488.88 EUR 488.88 € VAT Included

501.00 € VAT Included

(488.88 € / pcs)

Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Filtration Group

Filtration Group

Filtration Group's filtration and separation solutions ensure success, guarantee trouble-free plant operation, promote clean working environments and protect valuable capital goods

Product no. :

77694144

Category :

Filtration Group Low Pressure Filter

Weight :

1.70 kg

Filtration Group (formerly MAHLE) Low pressure filter Pi 2728-69 / 77694144

  • Intended for installation in pipes
  • Modular system for optimum filter selection
  • Flow-optimized design of the components, resulting in minimal pressure loss
  • Compact design means less space required
  • Electrical maintenance indicator
  • Version with threaded connections
  • Available with high-efficiency Mic or Sm-x filter elements
  • Guaranteed separation rates according to multi-pass test in accordance with ISO 16889
  • High dirt holding capacity and differential pressure stability of the elements

    • When using filters without a bypass, it must be ensured that the maximum differential pressure of the filter element is not exceeded

    Important note:
    We supply the Mahle low-pressure filter Pi 2728-69 without the filter elements.
    For suitable filter elements and accessories, see "Accessories".

    Connection type Thread ISO 228
    Connection size G 11/2
    Display pressure of contamination indicator (bar) 2,2
    Evaluation of pollution indicators electrical / mechanical
    Operating temperature -10°C bis +120°C
    Contact type Contamination indicator Closer / Opener
    Max. Operating pressure (bar) 10
    Nominal size 315
    Type Contamination indicator VA Differential pressure
    Contamination indicator ja
    Filter head material ALU
