Filtration Group High pressure filter Pi 40040-010 FL

Price:

648.34 €
    ​
English (US)
  2. Shop
  3. High Pressure Filter
  4. Filtration Group High pressure filter Pi 40040-010 FL
Filtration Group High pressure filter Pi 40025-014
Filtration Group High pressure filter Pi 40025-014
585.74 €
585.74 €
Filtration Group High pressure filter Pi 40040-012 FL
Filtration Group High pressure filter Pi 40040-012 FL
826.46 €
826.46 €

Filtration Group High pressure filter Pi 40040-010 FL

https://www.filcom-technik.de/web/image/product.template/233816/image_1920?unique=c0c8d8f

High-pressure filter Pi 4 DIN 2455
Nominal size 4 l/min,
includes:
- Hole for maintenance indicator

648.34 € 648.34 EUR 648.34 € VAT Included

681.03 € VAT Included

  • Brand

This combination does not exist.

from 110 € free shipping Details shipping costs
Contact Us
Filtration Group
Filtration Group

Filtration and separation solutions from Filtration Group are designed to ensure success: they guarantee smooth plant operation, contribute to cleanliness in work environments and environmental protection, and safeguard valuable assets

Product no. :
78207821
Category :
High Pressure Filter
Weight :
18.50 kg

Filtration Group (formerly MAHLE) High-pressure filter Pi 40040-010 FL / 78207821

  • Low space requirement due to compact design
  • Modular system for optimum filter selection
  • Minimal pressure loss due to streamlined design of the components
  • Available with high-efficiency PS filter elements
  • Guaranteed separation rates according to multi-pass test in accordance with ISO 16889
  • High dirt holding capacity and differential pressure stability of the elements

    • When using filters without a bypass, it must be ensured that the maximum differential pressure of the filter element is not exceeded.


    Important note:
    We supply the Mahle Pi 44-1 high-pressure filter without the filter element.
    For suitable filter elements and accessories, see "Accessories".

    Anschlussart Flansch ISO 6162-2
    Contact type Contamination indicator eingeschraubtem Blindstopfen für VA
    Filter housing material Stahl
    Betriebstemperatur (°C) -10°C bis +120°C
    Connection size DN 38
    Nenngröße 400
    Werkstoff Filterkopf GGG
    Seal material NBR
    Max. Operating pressure (bar) 400
    FG-Datenblatt_Pi4000_NG400_de
    Download
    ​
