RIEGLER 3/2-way solenoid valve, Banjo connection, NC, 24 DC
Type number: 108.02
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER 3/2-way solenoid valve made of polyamide (glass fiber reinforced), for industrial systems, max. 10 bar - Type 108.02
The RIEGLER 3/2-way solenoid valve, Banjo, NC, 24 DC, G 1/8 AG, PN 10 bar switches compressed air and media flows electrically controlled via a solenoid coil. The housing is made of polyamide (glass fiber reinforced) with NBR seals. Designed for a maximum operating pressure of 10 bar. The operating temperature is between 0 °C and 60 °C. Connection thread G 1/8 AG - suitable for common industry standards. Operating voltage 24 DC. Fast, precise switching for automated processes.
Field of application
Typical areas of application: Automation, mechanical engineering and process technology.
| Housing | Polyamide (glass fiber reinforced) |
| Sealing material | NBR |
| Max. operating pressure | 10 bar |
| Medium temperature min. | -10 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -10 °C |
| Ambient temperature max. | 60 °C |
| Operating temperature min. | 0 °C |
| Operating temperature max. | 60 °C |
| Thread | G 1/8 AG |
| Function | normally closed (NC) |
| Connection | Push-in connection for hose outer Ø 4 mm |
| Connection | Thread G 1/8 |
| Tension | 24 DC |
| A | 79 mm |
| B | 90 mm |
| C | 49 mm |
| D | 58 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Vent connection | M5 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | none |
| Class name | MAX |
