RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 3/8
Type number: 392.23
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Ball valve, high-pressure version, female G-thread, steel, operating temperature -10 °C to 100 °C, G 3/8, DN 10, PN max. 500 bar
| Housing | Steel |
| Max. operating pressure | 500 bar |
| Ball | Hard chrome-plated steel |
| Operating temperature min. | -10 °C |
| Operating temperature max. | 100 °C |
| Shift shaft | Steel |
| Switching ball seal | POM |
| Shift shaft seal | NBR |
| Thread | G 3/8 |
| DN | 10 |
| A | 100 mm |
| B | 68 mm |
| L | 73 mm |
| Class name | FLEX |
