RIEGLER 3/2-way valve, NAMUR, monostable, NC, G 1/4, 24 V DC

Price:

49.63 €
    ​
English (US)
  2. Shop
  3. Control Valves
  4. RIEGLER 3/2-way valve, NAMUR, monostable, NC, G 1/4, 24 V DC
RIEGLER 5/2-way valve, Mechanically actuated, »M5«, Roller lever, G 1/4
RIEGLER 5/2-way valve, Mechanically actuated, »M5«, Roller lever, G 1/4
36.95 € 36.95 €
RIEGLER 3/2-way valve, Pneumatic, bistable, Connection G 3/8
RIEGLER 3/2-way valve, Pneumatic, bistable, Connection G 3/8
77.58 € 77.58 €

RIEGLER 3/2-way valve, NAMUR, monostable, NC, G 1/4, 24 V DC

https://www.filcom-technik.de/web/image/product.template/171622/image_1920?unique=fc06005

Type number: 551.22

49.63 € 49.63 EUR 49.63 € VAT Included

57.93 € VAT Included

Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers
from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.

Product no. :

103660

EAN :

4047322272476

Category :

Namur Valves

Weight :

0.26 kg

3/2-way valve, NAMUR, mono, NC, anodized aluminium, max. operating temp. 70 °C, operating pressure 1.5 - 10 bar, DN 7, connection G 1/4, 24 V DC

Medium Air, neutral gases (filtered)
Housing Anodized aluminum
Sealing material NBR
Electrical connection Device plug PG 9
Working pressure min. 1.5 bar
Working pressure max. 10 bar
Operating temperature min. -20 °C
Operating temperature max. 70 °C
Slider Stainless steel
Manual override resting
Flow rate 1250 l/min
DN 7
Scope of delivery Device plug PG 9, 1 coding pin, 2 O-rings, 2 screws
Tension 24 V DC
REACH SVHC1 Substance Name Lead
CAS No. SVHC 1 7439-92-1
Connection G 1/4
RoHS material information RoHS compliant
RoHS Directive 2011/65/EU, 2015/863/EU, 2018/741/EU
RoHS Article of the Directive Article 4, paragraph 1, Annex 3
Share of SVHC substance in % for RoHS 0.04
Exception 6c
REACH Info contains SVHC substance
Share of SVHC SCIP >= 1.0% w/w and < 10.0% w/w
Proportion of SVHC substance in SCIP >= 0.1 % in w/w
Material identification none
Class name PLUS

Variants / Alternatives

Product Price
[103659] RIEGLER 3/2-way valve, NAMUR, monostable, NC, G 1/4, 230 V, 50Hz

Type number: 551.21

 49.63 €

Accessoires and suitable extensions

Product Price
[103663] RIEGLER Throttle plate for NAMUR valves, 3-way, Knurled screw

Type number: 551.41

 102.55 €
