RIEGLER Bushing - locking pusher, Stainless steel 1.4401/1.4408, G 1 1/2
Type number: 250.38 ES
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Socket gate valve, stainless steel 1.4401/1.4408, max. medium temperature 120 °C, G 1 1/2, DN 40, PN max. 14 bar
| Housing | Stainless steel 1.4401 / 1.4408 |
| Sealing material | PTFE |
| Max. operating pressure | 14 bar |
| Medium temperature max. | 160 °C |
| Ambient temperature max. | 160 °C |
| Interior parts | Stainless steel 1.4401 / 1.4408 |
| Handwheel | Aluminum |
| Operating temperature min. | -10 °C |
| Operating temperature max. | 80 °C |
| Thread | G 1 1/2 |
| DN | 40 |
| A | 90 mm |
| B | 147 mm |
| L | 85 mm |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| RoHS material information | RoHS compliant |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Class name | STAINLESS STEEL |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[103785] RIEGLER Bushing - locking pusher, Stainless steel 1.4401/1.4408, G 1](/web/image/product.template/171746/image_128/%5B103785%5D%20RIEGLER%20Bushing%20-%20locking%20pusher%2C%20Stainless%20steel%201.4401-1.4408%2C%20G%201?unique=51c468d)
|
Type number: 250.36 ES |
97.63 € | |
![[103786] RIEGLER Bushing - locking pusher, Stainless steel 1.4401/1.4408, G 1 1/4](/web/image/product.template/171747/image_128/%5B103786%5D%20RIEGLER%20Bushing%20-%20locking%20pusher%2C%20Stainless%20steel%201.4401-1.4408%2C%20G%201%201-4?unique=cfcfc54)
|
Type number: 250.37 ES |
121.33 € | |
![[103783] RIEGLER Bushing - locking pusher, Stainless steel 1.4401/1.4408, G 1/2](/web/image/product.template/171744/image_128/%5B103783%5D%20RIEGLER%20Bushing%20-%20locking%20pusher%2C%20Stainless%20steel%201.4401-1.4408%2C%20G%201-2?unique=d441654)
|
Type number: 250.34 ES |
65.35 € | |
![[103788] RIEGLER Bushing - locking pusher, Stainless steel 1.4401/1.4408, G 2](/web/image/product.template/171749/image_128/%5B103788%5D%20RIEGLER%20Bushing%20-%20locking%20pusher%2C%20Stainless%20steel%201.4401-1.4408%2C%20G%202?unique=7232617)
|
Type number: 250.39 ES |
213.76 € | |
![[103784] RIEGLER Bushing - locking pusher, Stainless steel 1.4401/1.4408, G 3/4](/web/image/product.template/171745/image_128/%5B103784%5D%20RIEGLER%20Bushing%20-%20locking%20pusher%2C%20Stainless%20steel%201.4401-1.4408%2C%20G%203-4?unique=1663f36)
|
Type number: 250.35 ES |
77.42 € | |
