RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 1.6 bar/23 psi
Type number: 202-KDE
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Standardmano. »pressure line«, Kunststoffgeh., Anschluss hinten zentr., G 1/4, Güteklasse 2,5, Messber. 0 - 1,6 bar/23 psi, Ø 50
| Housing | Plastic |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | Plastic |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 1.6 |
| Diameter | 50 mm |
| Graduation value in the bar range | 0.1 bar |
| Execution | Bourdon tube pressure gauge |
| Connection | G 1/4 |
| Quality class | 45414 |
| Lower / Upper measuring range limit | Overpressure |
| Connection position | rear, centric |
| Class name | EASY |
| Process connection material | Copper alloy |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[115496] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 10 bar/145 psi](/web/image/product.template/200255/image_128/%5B115496%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%2010%20bar-145%20psi?unique=bf9c19a)
|
Type number: 206-KDE |
6.20 € | |
![[115504] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 10 bar/150 psi](/web/image/product.template/200263/image_128/%5B115504%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%2010%20bar-150%20psi?unique=cae6748)
|
Type number: 217-EN |
7.37 € | |
![[115505] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 16 bar/230 psi](/web/image/product.template/200264/image_128/%5B115505%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%2016%20bar-230%20psi?unique=baeb951)
|
Type number: 218-EN |
7.37 € | |
![[115497] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 16 bar/230 psi](/web/image/product.template/200256/image_128/%5B115497%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%2016%20bar-230%20psi?unique=3c7599e)
|
Type number: 207-KDE |
6.20 € | |
![[115500] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 1.6 bar/23 psi](/web/image/product.template/200259/image_128/%5B115500%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%201.6%20bar-23%20psi?unique=54c838a)
|
Type number: 213-EN |
7.37 € | |
![[115491] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 1 bar/14.5 psi](/web/image/product.template/200250/image_128/%5B115491%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%201%20bar-14.5%20psi?unique=751bccb)
|
Type number: 201-KDE |
6.20 € | |
![[115499] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 1 bar/15 psi](/web/image/product.template/200258/image_128/%5B115499%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%201%20bar-15%20psi?unique=3c56946)
|
Type number: 212-EN |
7.37 € | |
![[115501] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 2.5 bar/36 psi](/web/image/product.template/200260/image_128/%5B115501%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%202.5%20bar-36%20psi?unique=c3185e2)
|
Type number: 214-EN |
7.37 € | |
![[115493] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 2.5 bar/36 psi](/web/image/product.template/200252/image_128/%5B115493%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%202.5%20bar-36%20psi?unique=c625492)
|
Type number: 203-KDE |
6.20 € | |
![[115494] RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 4 bar/56 psi](/web/image/product.template/200253/image_128/%5B115494%5D%20RIEGLER%20Standard%20pressure%20gauge%20%C2%BBpressure%20line%C2%AB%20G%201-4%2C%200%20-%204%20bar-56%20psi?unique=3f38f63)
|
