RIEGLER Capsule pressure gauge, G 1/4 radial bottom, -160 / 0 mbar, Ø 63
Type number: ZRL1S.630635
EAN: 4047322699372
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Capsule pressure gauge, steel case, black, radial bottom connection, G 1/4, grade 1.6, range no. -160 / 0 mbar, Ø 63
| Housing | Steel, black |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Area of application | for gaseous, dry and non-aggressive media |
| Measuring element | Copper alloy |
| Pointer movement | Brass |
| Diameter | 63 mm |
| Connection | G 1/4 |
| Graduation value in the mbar range | 5 mbar |
| Quality class | 45444 |
| Lower / Upper measuring range limit | Vacuum |
| Measuring range min. mbar | -160 |
| Measuring range max. mbar | 0 |
| Connection position | radial bottom |
| Class name | PLUS |
| Viewing window | Plastic, clipped in |
| Process connection material | Brass |
