Filtration Group Low pressure filter Pi 2720-057

Low-pressure filter Pi 272-57
Nominal size 25 l/min
Includes:
- Bypass 3.5 bar
- Visual maintenance indicator

425.45 € 425.45 EUR 425.45 € VAT Included

436.00 € VAT Included

Brand

This combination does not exist.

Add to Cart

from 110 € free shipping Details shipping costs

Filtration Group

Filtration and separation solutions from Filtration Group are designed to ensure success: they guarantee smooth plant operation, contribute to cleanliness in work environments and environmental protection, and safeguard valuable assets

Product no. :

77694078

Category :

Filtration Group Low Pressure Filter

Weight :

1.70 kg

Filtration Group (formerly MAHLE) Low pressure filter Pi 2720-057 / 77694078

Intended for installation in pipes

Modular system for optimum filter selection

Flow-optimized design of the components, resulting in minimal pressure loss

Compact design means less space required

Bypass 3.5 bar

Visual maintenance indicator

Version with threaded connections

Available with high-efficiency Mic or Sm-x filter elements

Guaranteed separation rates according to multi-pass test in accordance with ISO 16889

High dirt holding capacity and differential pressure stability of the elements

Important note:
We supply the Mahle low-pressure filter Pi 272-57 without the filter elements.
For suitable filter elements and accessories, see "Accessories".

Connection type	Thread ISO 228
Connection size	G 11/2
Display pressure of contamination indicator (bar)	2,2
Evaluation of pollution indicators	optical
Operating temperature	-10°C bis +120°C
Bypass valve Opening pressure (bar)	3,5
Contact type Contamination indicator	Closer / Opener
Max. Operating pressure (bar)	16
Nominal size	250
Type Contamination indicator	VA Differential pressure
Contamination indicator	ja
Seal material	NBR/AL
Filter housing material	Steel
Filter head material	GAL

FG-Datenblatt_Pi270_NG315_de-1

Download
