RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 1
Type number: 392.27
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Ball valve, high-pressure version, female G-thread, steel, operating temperature -10 °C to 100 °C, G 1, DN 25, PN max. 420 bar
| Housing | Steel |
| Max. operating pressure | 420 bar |
| Ball | Hard chrome-plated steel |
| Operating temperature min. | -10 °C |
| Operating temperature max. | 100 °C |
| Shift shaft | Steel |
| Switching ball seal | POM |
| Shift shaft seal | NBR |
| Thread | G 1 |
| DN | 25 |
| A | 187 mm |
| B | 128 mm |
| L | 115 mm |
| Class name | FLEX |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[103517] RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 1/2](/web/image/product.template/171479/image_128/%5B103517%5D%20RIEGLER%20Ball%20valve%2C%20High%20pressure%20design%2C%20G%20interior%20thread%2C%20Steel%2C%20G%201-2?unique=f1d7ee6)
|
Type number: 392.24 |
30.23 € | |
![[103515] RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 1/4](/web/image/product.template/171477/image_128/%5B103515%5D%20RIEGLER%20Ball%20valve%2C%20High%20pressure%20design%2C%20G%20interior%20thread%2C%20Steel%2C%20G%201-4?unique=6af5aba)
|
Type number: 392.22 |
23.63 € | |
![[103514] RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 1/8](/web/image/product.template/171476/image_128/%5B103514%5D%20RIEGLER%20Ball%20valve%2C%20High%20pressure%20design%2C%20G%20interior%20thread%2C%20Steel%2C%20G%201-8?unique=59d4f71)
|
Type number: 392.21 |
29.00 € | |
![[103519] RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 3/4](/web/image/product.template/171481/image_128/%5B103519%5D%20RIEGLER%20Ball%20valve%2C%20High%20pressure%20design%2C%20G%20interior%20thread%2C%20Steel%2C%20G%203-4?unique=78cdc71)
|
Type number: 392.26 |
52.88 € | |
![[103516] RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 3/8](/web/image/product.template/171478/image_128/%5B103516%5D%20RIEGLER%20Ball%20valve%2C%20High%20pressure%20design%2C%20G%20interior%20thread%2C%20Steel%2C%20G%203-8?unique=345be8d)
|
Type number: 392.23 |
27.27 € | |
![[103518] RIEGLER Ball valve, High pressure design, G interior thread, Steel, G 5/8](/web/image/product.template/171480/image_128/%5B103518%5D%20RIEGLER%20Ball%20valve%2C%20High%20pressure%20design%2C%20G%20interior%20thread%2C%20Steel%2C%20G%205-8?unique=99d3b4f)
|
Type number: 392.25 |
117.87 € | |
