RIEGLER 3/2-way mini valve, manual, Pull switch, NC bistable 4 mm side

https://www.filcom-technik.de/web/image/product.template/175468/image_1920?unique=a5aab98

Type number: 512.513

58.27 € 58.27 EUR 58.27 € VAT Included

68.02 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.

Product no. :

106411

EAN :

4047322096416

Category :

Valves Manually Operated

Weight :

0.09 kg

3/2-way miniature valve, manual, pull switch, NC, bistable, 4 mm lateral, operating pressure 0.5 - 10 bar, operating temperature -10°C to 60°C

Medium Filtered compressed air with or without lubrication. If lubricated, then continuous.
Sealing material NBR
Series Valves VME series
Operating pressure min. 0.5 bar
Max. operating pressure 10 bar
Operating temperature min. -10 °C
Operating temperature max. 60 °C
Spring stainless steel
Actuating pressure at 6 bar 8 N
Valve body Aluminum
Push button Nickel-plated brass
Function 3/2 NC
Actuation bistable
Nominal Ø 2.5 mm
REACH SVHC1 Substance Name Lead
CAS No. SVHC 1 7439-92-1
Connection Push-in connection Ø 4 mm on the side
RoHS material information RoHS compliant
Flow rate 35 Nl/min
Flow rate 60 Nl/min
RoHS Directive 2011/65/EU, 2015/863/EU, 2018/741/EU
RoHS Article of the Directive Article 4, paragraph 1, Annex 3
Share of SVHC substance in % for RoHS 0.04
Exception 6c
REACH Info contains SVHC substance
Share of SVHC SCIP >= 1.0% w/w and < 10.0% w/w
Proportion of SVHC substance in SCIP >= 0.1 % in w/w
Material identification CW614N
Flow rate measurement 1 Flow rate at 6 bar and Δp 0.5 bar
Flow rate measurement 2 Flow rate at 6 bar and Δp 1.0 bar
Class name PLUS
