RIEGLER Compact ejector »CP«, Digital vacuum switch, Nozzle size 2.5 mm
Type number: CP 254
EAN: 4047322198813
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Compact ejector "CP", digital vacuum switch, nozzle size 2.5 mm, NO, compressed air/vacuum connection G 1/4 IG, G 3/8 IG, PN 5 - 6 bar
| Operating pressure min. | 5 bar |
| Max. operating pressure | 6 bar |
| Base body | Anodized aluminum |
| Integrated | NC blow-off valve, filter, silencer, non-return valve |
| Height | 183 mm |
| Width | 22 mm |
| Length | 113 mm |
| Nozzle size | 2.5 mm |
| Compressed air connection | G 1/4 FEMALE THREAD |
| Vacuum connection | G 3/8 IG |
| Rest position suction valve | NO |
| Suction capacity max. | 161 l/min |
| Air consumption suction | 310 l/min |
| Weight | 485 g |
| Class name | MAX |
