RIEGLER Straight screw-in fitting, G 1/2 o., for hose 4/6 mm, AF 27, PFA
Type number: 120.31.603
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Straight screw-in fitting, G 1/2 a., for 4/6 mm tubing, SW 27, working pressure max. 10 bar (20 °C) / max. 1 bar (170 °C), PFA
| Material | Perfluoroalkoxy (PFA) |
| Operating temperature min. | 0 °C |
| Operating temperature max. | 200 °C |
| Max. operating pressure at 20 °C | 10 bar |
| Operating pressure max. from 170 °C | 1 bar |
| Thread | G 1/2 |
| SW | 27 mm |
| for hose | 4/6 mm |
| L1 | 43 mm |
| L2 | 14 mm |
| Class name | FLEX |
