RIEGLER Standard pressure gauge »pressure line« G 1/8, 0 - 2.5 bar/36 psi
Type number: 110.43-KDE
EAN: 4047322175739
Standard mano. "pressure line", plastic housing, connection rear center, G 1/8, grade 2.5, measuring range 0 - 2.5 bar/36 psi, Ø 40
| Housing | Plastic |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | Plastic |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 0 |
| Diameter | 40 mm |
| Graduation value in the bar range | 0.1 bar |
| Execution | Bourdon tube pressure gauge |
| Connection | G 1/8 |
| Quality class | 45414 |
| Lower / Upper measuring range limit | Overpressure |
| Connection position | rear, centric |
| Class name | EASY |
| Process connection material | Copper alloy |
