RIEGLER Angled screw-in fitting »value line«, rotating, M5 o.

Price:

1.58 €

RIEGLER Angled screw-in fitting »value line«, rotating, M5 o.
RIEGLER Angled screw-in fitting »value line«, rotating, M5 o.
1.51 € 1.51 €
RIEGLER Angled screw-in fitting »value line«, R 1/4 o., for hose Ø 6 mm
RIEGLER Angled screw-in fitting »value line«, R 1/4 o., for hose Ø 6 mm
1.51 € 1.51 €

RIEGLER Angled screw-in fitting »value line«, rotating, M5 o.

https://www.filcom-technik.de/web/image/product.template/200933/image_1920?unique=e0df65d

Type number: 54.005-6-E

EAN: 4047322183697

1.58 € 1.58 EUR 1.58 € VAT Included

2.78 € VAT Included


  • Brand

This combination does not exist.

from 110 € free shipping Details shipping costs

Riegler

Riegler

RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.


Product no. :

116200

EAN :

4047322183697

Category :

Male Elbows

Weight :

0.10 kg

Angle screw-in fitting "value line", rotatable, M5 a., for outer hose Ø 6, working pressure -0.98 to 16 bar, nickel-plated brass.

Medium Compressed air
Sealing material NBR, silicone-free
Series value line
Working pressure min. -0.98 bar
Working pressure max. 16 bar
Material Nickel-plated brass
Area of application Compressed air systems, vacuum
Operating temperature min. -20 °C
Operating temperature max. 80 °C
Solder ring Hostaform
Recommended hose PA, PU
Collet chuck Stainless steel AISI 316
Thread M5
SW 9 mm
for hose outer Ø 6 mm
L1 21 mm
L2 14.5 mm
REACH SVHC1 Substance Name Lead
CAS No. SVHC 1 7439-92-1
RoHS material information RoHS compliant
RoHS Directive 2011/65/EU, 2015/863/EU, 2018/741/EU
RoHS Article of the Directive Article 4, paragraph 1, Annex 3
Share of SVHC substance in % for RoHS 0.04
Exception 6c
REACH Info contains SVHC substance
Share of SVHC SCIP >= 1.0% w/w and < 10.0% w/w
Proportion of SVHC substance in SCIP >= 0.1 % in w/w
Material identification none
O-ring NBR
Class name EASY
