RIEGLER Pressure gauge, CrNi steel, rear eccentric, G 1/2, 0-16 bar, Ø100
Type number: 4095
EAN: 4047322484084
Pressure gauge in stainless steel design, eccentric rear connection, G 1/2, type 232.50, grade 1.0, measuring range 0 - 16.0 bar, Ø 100
| Medium temperature min. | -40 °C |
| Medium temperature max. | 200 °C |
| Ambient temperature min. | -40 °C |
| Ambient temperature max. | 60 °C |
| Material | CrNi steel |
| Type | 232.50 |
| Viewing window | Multi-layer safety glass |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 16 |
| Diameter | 100 mm |
| Graduation value in the bar range | 0.5 bar |
| Connection | G 1/2 |
| Quality class | 1 |
| Lower / Upper measuring range limit | Overpressure |
| Connection position | rear, eccentric |
| Class name | STAINLESS STEEL |
| Process connection material | CrNi steel |
