Donaldson compressed air filter elements
Maximum efficiency & process reliability for your compressed air station
Ensure the longevity of your systems with high-quality Donaldson Filter elementsEnsure the longevity of your systems with high-quality Donaldson filter elements. In the FILCOM online shop you will find the complete range of original replacement filters for professional compressed air treatment. Our Donaldson solutions are characterized by extremely low differential pressures, high dirt holding capacities and first-class filtration in accordance with ISO 8573-1. Whether for standard industry or sensitive processes - we have the right types from A to V available for you.
Nutzen Sie unseren Suchfilter, um das passende Filterelement schnell zu finden – oder verschaffen Sie sich mit der Vergleichstabelle einen Überblick über alle Donaldson Filterserien.
Donaldson compressed air filter elements - filter series at a glance
Donaldson Compressed air filter elements offer the right solution for every industrial compressed air treatment requirement. Whether coalescence filters for oil and water separation, activated carbon filters for oil-free compressed air or sterile filters for germ-free process air - all filter elements are designed for installation in Donaldson DF filter housings and tested in accordance with ISO 8573-1.
Donaldson filter series - comparison table
| Filter series | Designation | Filter fineness | Remaining oil content | Application |
|---|---|---|---|---|
| V | Pre-filter / coarse filter | 3 µm | - | Pre-separation of coarse particles and droplet water as the first filter stage |
| B | Dust filter / particle filter | 1 µm | - | Particle separation and solids filtration in compressed air treatment |
| SB | Dust filter (standard) | 1 µm | - | Standard dust filter for reliable particle retention |
| SBP | Dust filter Plus | 1 µm | - | Dust filter with increased service life and optimized dirt absorption |
| CF | Coalescence depth filter | 0.01 µm | <0.01 mg/m³ | Oil and aerosol separation through depth filtration - Coalescence filter for clean compressed air |
| CFP | Depth filter Plus | 0.01 µm | <0.01 mg/m³ | High-performance coalescence filter with reduced differential pressure for energy-efficient filtration |
| FF | UltraPleat™ fine filter | 0.01 µm | <0.01 mg/m³ | Pleated fine filter medium for high flow rates with low pressure loss |
| FFP | Fine filter Plus | 0.01 µm | <0.01 mg/m³ | Fine filter with extended service life and optimized filtration performance |
| FF HTCR | Fine filter (chemically resistant) | 0.01 µm | <0.01 mg/m³ | Chemically resistant fine filter for aggressive media and corrosive environments |
| FF HTNX | Fine filter (high temperature) | 0.01 µm | <0.01 mg/m³ | High-temperature fine filter for compressed air applications at elevated operating temperatures |
| MF | UltraPleat™ microfilter | 0.01 µm | - | Pleated microfilter for fine particle separation with high flow rate |
| MF HTCR | Microfilter (chemically resistant) | 0.01 µm | - | Chemically resistant microfilter for aggressive media |
| MF HTNX | Microfilter (high temperature) | 0.01 µm | - | High-temperature microfilters for thermally stressed compressed air systems |
| S | Submicrofilter (standard) | 0.01 µm | - | Ultra-fine filtration for germ-free compressed air in the pharmaceutical and food industries |
| SMF | UltraPleat™ submicron filter | 0.01 µm | - | Pleated submicron filter - sterile filter for the highest compressed air quality |
| SMF HTCR | Submicrofilter (Chem. best.) | 0.01 µm | - | Chemically resistant sterile filter for aggressive environments |
| SMF HTNX | Submicrofilter (high temp.) | 0.01 µm | - | High-temperature sterile filters for thermally demanding sterile processes |
| A | Activated carbon | - | 0.003 mg/m³ | Adsorption filter for oil-free and odorless compressed air |
| AK | Activated carbon adsorption | - | 0.003 mg/m³ | Activated carbon adsorption filter for the highest compressed air quality in accordance with ISO 8573-1 |
Donaldson filter series - overview list
V - Pre-filter / coarse filter (3 µm)
B - Dust filter / particle filter (1 µm)
SB - Dust filter (standard) (1 µm)
SBP - Dust filter Plus (1 µm)
CF - Coalescence depth filter (0.01 µm, residual oil <0.01 mg/m³)
CFP - Depth Filter Plus (0.01 µm, residual oil <0.01 mg/m³)
FF - UltraPleat™ fine filter (0.01 µm, residual oil <0.01 mg/m³)
FFP - Fine Filter Plus (0.01 µm, residual oil <0.01 mg/m³)
FF HTCR - Fine filter (chemically resistant) (0.01 µm, residual oil <0.01 mg/m³)
FF HTNX - Fine filter (high temperature) (0.01 µm, residual oil <0.01 mg/m³)
MF - UltraPleat™ microfilter (0.01 µm)
MF HTCR - Microfilter (chemically resistant) (0.01 µm)
MF HTNX - Microfilter (high temperature) (0.01 µm)
S - Submicron filter (standard) (0.01 µm)
SMF - UltraPleat™ submicron filter (0.01 µm)
SMF HTCR - Submicron filter (chem. best.) (0.01 µm)
SMF HTNX - Submicron filter (high temp.) (0.01 µm)
A - activated carbon (-, residual oil <0.003 mg/m³)
AK - activated carbon adsorption (-, residual oil <0.003 mg/m³)
Which Donaldson filter element is the right one?
The choice of the right Donaldson compressed air filter depends on the desired compressed air quality in accordance with ISO 8573-1. Multi-stage filtration is recommended for typical industrial compressed air treatment: first a pre-filter from the V series for coarse separation, then a coalescence filter from the CF/FF series for oil and aerosol separation and, if required, an activated carbon filter from the A/AK series for oil-free compressed air. The HTCR variants are available for chemically aggressive media and the HTNX series for higher temperatures. In hygiene-critical areas, submicrofilters from the S/SMF series ensure germ-free process air.
All Donaldson filter elements are designed for use in DF filter housings and guarantee consistently high filtration performance over the entire service life. If you have any questions about filter selection or conversion of Donaldson filter designations, we will be happy to advise you - contact our team in the FILCOM online shop.
