RIEGLER Basic ejector »SBP«, Silencer, Nozzle size 0.5 mm
Type number: SBP 05
EAN: 4047322206389
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Basic ejector "SBP", high vacuum, silencer, nozzle size 0.5 mm, compressed air/vacuum connection 4 mm, PN max. 4.5 bar
| Housing | Plastic (impact-resistant) |
| Max. operating pressure | 4.5 bar |
| Silencer | Plastic |
| Height | 28 mm |
| Width | 10 mm |
| Length | 71 mm |
| Connection | push in connector |
| Nozzle size | 0.5 mm |
| Compressed air connection | 4 mm |
| Vacuum connection | 4 mm |
| Evacuation level | 0.85 |
| Suction capacity max. | 8 l/min |
| Air consumption suction | 14 l/min |
| Weight | 7.5 g |
| Class name | PLUS |
