RIEGLER pressure regulator for drinking water, gunmetal, w. Mano, G 3/4 IG, 1 - 8 bar
Typennummer: DRTWR.G34.1-8B
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Pressure regulator for potable water made of gunmetal (CC499K), for compressed air treatment, 1 bar - Type DRTWR.G34.1-8B
The RIEGLER pressure regulator for drinking water, gunmetal, w. Mano, G 3/4 IG, 1 - 8 bar reduces the inlet pressure precisely to a constant working pressure and protects downstream consumers from pressure fluctuations. The housing is made of gunmetal (CC499K) with EPDM seals. The control range extends from 1 bar to 8 bar with a maximum inlet pressure of 40 bar. The operating temperature is between -20 °C and 95 °C. Connection thread G 3/4 IG - suitable for common industry standards. Suitable for drinking water, nitrogen, argon, neutral and non-adhesive liquids, compressed air and neutral gases. Uniform working pressure for constant process quality.
Field of application
Typical areas of application: Compressed air treatment, machine supply and process control.
| Operating temperature max. drinking water | 80 °C |
| Interior parts | Gunmetal (CC499K) and stainless steel (1.4404) |
| Housing | Gunmetal (CC499K) |
| Medium | Drinking water, nitrogen, argon, neutral and non-adhesive liquids, compressed air and neutral gases |
| SW | 35 mm |
| Control range max. | 8 bar |
| DN | 20 |
| Operating temperature min. | -20 °C |
| Control range min. | 1 bar |
| D | 102 mm |
| Flow rate kvs-value | 3.5 m³/h |
| C | 33 mm |
| Inlet pressure max. | 40 bar |
| Operating temperature max. | 95 °C |
| A | 95 mm |
| Sealing material | EPDM |
| Class name | FLEX |
| Thread | G 3/4 IG |
