RIEGLER Service unit 3-part »multifix«, Protective cage, Size 1, G 1/4

Price:

104.66 €

RIEGLER Service unit 3-part »multifix« with PC container, Size 5, G 1
RIEGLER Service unit 3-part »multifix« with PC container, Size 5, G 1
365.02 € 365.02 €
RIEGLER Service unit 3-part »multifix«, Protective cage, Size 1, G 3/8
RIEGLER Service unit 3-part »multifix«, Protective cage, Size 1, G 3/8
104.66 € 104.66 €

RIEGLER Service unit 3-part »multifix«, Protective cage, Size 1, G 1/4

https://www.filcom-technik.de/web/image/product.template/140021/image_1920?unique=ca2380b

Type number: FRL 11 S

EAN: 4047322131988

104.66 € 104.66 EUR 104.66 € VAT Included

162.87 € VAT Included


  • Brand

This combination does not exist.

from 110 € free shipping Details shipping costs

Riegler

Riegler

RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.


Product no. :

100586

EAN :

4047322131988

Weight :

1.14 kg

3-piece "multifix" maintenance unit, PC container and protective cage, BG 1, G 1/4, max. inlet pressure 16 bar, control range 0.5 - 10 bar

Inlet pressure max. 16 bar
Housing Zinc die casting
Sealing material NBR
Flow rate measurement at P<sub>1</sub> = 10 bar, P<sub>2</sub> = 6.3 bar and pressure drop Î"<sub>p</sub> = 1 bar
Series multifix
Container Polycarbonate container with protective cage
Filter fineness 5 µm
Dropper attachment PA
Medium temperature min. -10 °C
Medium temperature max. 60 °C
Ambient temperature min. -10 °C
Ambient temperature max. 60 °C
Spring cover POM brass
Thread G 1/4
Flow rate 1200 l/min
Control range min. 0.5 bar
Control range max. 10 bar
Condensate drain semi-automatic
DN 6
Pressure gauge display min. 0 bar
Pressure gauge display max. 16 bar
BG 1
A 137.8 mm
B 192.1 mm
C 67 mm
D 125.1 mm
Class name PLUS
