RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 200
Type number: 6.DD.400200
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Rodless cylinder, double-acting, solenoid, piston Ø 40, stroke 200, G 1/4, working pressure 1 - 8 bar, temp. -10 °C to 80 °C
| Temperature range min. | -10 °C |
| Temperature range max. | 80 °C |
| Housing | Profile tube made of aluminium alloy, anodized |
| Sealing material | NBR (for speeds up to max. 1 m/s) |
| Working pressure min. | 1 bar |
| Working pressure max. | 8 bar |
| Carriage (piston guide) | Aluminium alloy, anodized |
| Sealing tapes | Stainless steel |
| Piston Ø | 40 mm |
| Function | double-acting |
| Stroke | 200 mm |
| Force at 6 bar | 640 N |
| Side load max. | 4 Nm |
| Connection | G 1/4 |
| Class name | PLUS |
| Magnet | with magnet |
| Damping | with adjustable damping |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[106299] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 100](/web/image/product.template/175356/image_128/%5B106299%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20100?unique=05d661b)
|
Type number: 6.DD.160100 |
355.25 € | |
![[106308] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 1000](/web/image/product.template/175365/image_128/%5B106308%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%201000?unique=65d542a)
|
Type number: 6.DD.161000 |
444.81 € | |
![[106309] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 1200](/web/image/product.template/175366/image_128/%5B106309%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%201200?unique=f2d6014)
|
Type number: 6.DD.161200 |
464.70 € | |
![[106310] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 1400](/web/image/product.template/175367/image_128/%5B106310%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%201400?unique=c02cd22)
|
Type number: 6.DD.161400 |
491.33 € | |
![[106300] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 200](/web/image/product.template/175357/image_128/%5B106300%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20200?unique=4e5bbe2)
|
Type number: 6.DD.160200 |
370.28 € | |
![[106311] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 2000](/web/image/product.template/175368/image_128/%5B106311%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%202000?unique=068b98e)
|
Type number: 6.DD.162000 |
544.88 € | |
![[106301] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 300](/web/image/product.template/175358/image_128/%5B106301%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20300?unique=29d5523)
|
Type number: 6.DD.160300 |
380.36 € | |
![[106302] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 400](/web/image/product.template/175359/image_128/%5B106302%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20400?unique=084c3b2)
|
Type number: 6.DD.160400 |
385.11 € | |
![[106303] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 500](/web/image/product.template/175360/image_128/%5B106303%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20500?unique=0c1a058)
|
Type number: 6.DD.160500 |
401.72 € | |
![[106304] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 600](/web/image/product.template/175361/image_128/%5B106304%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20600?unique=0bf0882)
|
Type number: 6.DD.160600 |
411.85 € | |
![[106305] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 700](/web/image/product.template/175362/image_128/%5B106305%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20700?unique=6c34f20)
|
Type number: 6.DD.160700 |
414.95 € | |
![[106306] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 800](/web/image/product.template/175363/image_128/%5B106306%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20800?unique=6836f93)
|
Type number: 6.DD.160800 |
430.79 € | |
![[106307] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 16, Stroke 900](/web/image/product.template/175364/image_128/%5B106307%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2016%2C%20Stroke%20900?unique=0e543dd)
|
Type number: 6.DD.160900 |
440.90 € | |
![[106312] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 100](/web/image/product.template/175369/image_128/%5B106312%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20100?unique=6ecaf30)
|
Type number: 6.DD.250100 |
410.85 € | |
![[106321] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 1000](/web/image/product.template/175378/image_128/%5B106321%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%201000?unique=0a98042)
|
Type number: 6.DD.251000 |
503.93 € | |
![[106322] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 1200](/web/image/product.template/175379/image_128/%5B106322%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%201200?unique=e2392ff)
|
Type number: 6.DD.251200 |
527.79 € | |
![[106323] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 1400](/web/image/product.template/175380/image_128/%5B106323%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%201400?unique=0894cc4)
|
Type number: 6.DD.251400 |
555.41 € | |
![[106313] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 200](/web/image/product.template/175370/image_128/%5B106313%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20200?unique=8f79ad2)
|
Type number: 6.DD.250200 |
416.18 € | |
![[106324] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 2000](/web/image/product.template/175381/image_128/%5B106324%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%202000?unique=70c5534)
|
Type number: 6.DD.252000 |
622.13 € | |
![[106314] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 300](/web/image/product.template/175371/image_128/%5B106314%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20300?unique=8295e97)
|
Type number: 6.DD.250300 |
434.36 € | |
![[106315] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 400](/web/image/product.template/175372/image_128/%5B106315%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20400?unique=d70eb1e)
|
Type number: 6.DD.250400 |
438.13 € | |
![[106316] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 500](/web/image/product.template/175373/image_128/%5B106316%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20500?unique=47607f0)
|
Type number: 6.DD.250500 |
456.66 € | |
![[106317] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 600](/web/image/product.template/175374/image_128/%5B106317%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20600?unique=5f5c9b5)
|
Type number: 6.DD.250600 |
461.40 € | |
![[106318] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 700](/web/image/product.template/175375/image_128/%5B106318%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20700?unique=3014f48)
|
Type number: 6.DD.250700 |
477.57 € | |
![[106319] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 800](/web/image/product.template/175376/image_128/%5B106319%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20800?unique=af0b212)
|
Type number: 6.DD.250800 |
490.13 € | |
![[106320] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 25, Stroke 900](/web/image/product.template/175377/image_128/%5B106320%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2025%2C%20Stroke%20900?unique=3c355f5)
|
Type number: 6.DD.250900 |
492.95 € | |
![[106325] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 100](/web/image/product.template/175382/image_128/%5B106325%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20100?unique=16321a1)
|
Type number: 6.DD.320100 |
488.28 € | |
![[106334] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 1000](/web/image/product.template/175391/image_128/%5B106334%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%201000?unique=3440195)
|
Type number: 6.DD.321000 |
595.15 € | |
![[106335] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 1200](/web/image/product.template/175392/image_128/%5B106335%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%201200?unique=c58b56a)
|
Type number: 6.DD.321200 |
618.88 € | |
![[106336] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 1400](/web/image/product.template/175393/image_128/%5B106336%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%201400?unique=dbe8317)
|
Type number: 6.DD.321400 |
642.64 € | |
![[106326] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 200](/web/image/product.template/175383/image_128/%5B106326%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20200?unique=494ddd5)
|
Type number: 6.DD.320200 |
501.34 € | |
![[106337] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 2000](/web/image/product.template/175394/image_128/%5B106337%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%202000?unique=be315ca)
|
Type number: 6.DD.322000 |
723.81 € | |
![[106327] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 300](/web/image/product.template/175384/image_128/%5B106327%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20300?unique=b8b96b2)
|
Type number: 6.DD.320300 |
513.45 € | |
![[106328] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 400](/web/image/product.template/175385/image_128/%5B106328%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20400?unique=8053b5b)
|
Type number: 6.DD.320400 |
531.19 € | |
![[106329] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 500](/web/image/product.template/175386/image_128/%5B106329%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20500?unique=73665ea)
|
Type number: 6.DD.320500 |
537.34 € | |
![[106330] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 600](/web/image/product.template/175387/image_128/%5B106330%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20600?unique=569e214)
|
Type number: 6.DD.320600 |
555.25 € | |
![[106331] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 700](/web/image/product.template/175388/image_128/%5B106331%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20700?unique=5b53869)
|
Type number: 6.DD.320700 |
561.19 € | |
![[106332] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 800](/web/image/product.template/175389/image_128/%5B106332%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20800?unique=c92a1b9)
|
Type number: 6.DD.320800 |
573.08 € | |
![[106333] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 32, Stroke 900](/web/image/product.template/175390/image_128/%5B106333%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2032%2C%20Stroke%20900?unique=ac55985)
|
Type number: 6.DD.320900 |
591.36 € | |
![[106338] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 100](/web/image/product.template/175395/image_128/%5B106338%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20100?unique=6c73c80)
|
Type number: 6.DD.400100 |
535.74 € | |
![[106347] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 1000](/web/image/product.template/175404/image_128/%5B106347%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%201000?unique=0e20f2c)
|
Type number: 6.DD.401000 |
742.89 € | |
![[106348] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 1200](/web/image/product.template/175405/image_128/%5B106348%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%201200?unique=f492a1c)
|
Type number: 6.DD.401200 |
800.22 € | |
![[106349] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 1400](/web/image/product.template/175406/image_128/%5B106349%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%201400?unique=8d6aaa9)
|
Type number: 6.DD.401400 |
847.22 € | |
![[106350] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 2000](/web/image/product.template/175407/image_128/%5B106350%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%202000?unique=6d8ae81)
|
Type number: 6.DD.402000 |
988.25 € | |
![[106340] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 300](/web/image/product.template/175397/image_128/%5B106340%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20300?unique=1f39c8b)
|
Type number: 6.DD.400300 |
580.62 € | |
![[106341] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 400](/web/image/product.template/175398/image_128/%5B106341%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20400?unique=e963bcb)
|
Type number: 6.DD.400400 |
612.21 € | |
![[106342] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 500](/web/image/product.template/175399/image_128/%5B106342%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20500?unique=e965062)
|
Type number: 6.DD.400500 |
626.99 € | |
![[106343] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 600](/web/image/product.template/175400/image_128/%5B106343%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20600?unique=509b0ab)
|
Type number: 6.DD.400600 |
650.17 € | |
![[106344] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 700](/web/image/product.template/175401/image_128/%5B106344%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20700?unique=8c2495c)
|
Type number: 6.DD.400700 |
673.35 € | |
![[106345] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 800](/web/image/product.template/175402/image_128/%5B106345%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20800?unique=5aa0d4f)
|
Type number: 6.DD.400800 |
696.53 € | |
![[106346] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 40, Stroke 900](/web/image/product.template/175403/image_128/%5B106346%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2040%2C%20Stroke%20900?unique=325006c)
|
Type number: 6.DD.400900 |
719.71 € | |
![[106351] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 100](/web/image/product.template/175408/image_128/%5B106351%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20100?unique=9cd0074)
|
Type number: 6.DD.630100 |
797.34 € | |
![[106360] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 1000](/web/image/product.template/175417/image_128/%5B106360%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%201000?unique=fe344ce)
|
Type number: 6.DD.631000 |
1,109.40 € | |
![[106361] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 1200](/web/image/product.template/175418/image_128/%5B106361%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%201200?unique=c41833a)
|
Type number: 6.DD.631200 |
1,179.29 € | |
![[106362] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 1400](/web/image/product.template/175419/image_128/%5B106362%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%201400?unique=24726f4)
|
Type number: 6.DD.631400 |
1,266.53 € | |
![[106352] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 200](/web/image/product.template/175409/image_128/%5B106352%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20200?unique=7571065)
|
Type number: 6.DD.630200 |
829.88 € | |
![[106363] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 2000](/web/image/product.template/175420/image_128/%5B106363%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%202000?unique=528443c)
|
Type number: 6.DD.632000 |
1,458.81 € | |
![[106353] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 300](/web/image/product.template/175410/image_128/%5B106353%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20300?unique=6f1b012)
|
Type number: 6.DD.630300 |
867.51 € | |
![[106354] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 400](/web/image/product.template/175411/image_128/%5B106354%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20400?unique=baff2f8)
|
Type number: 6.DD.630400 |
910.33 € | |
![[106355] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 500](/web/image/product.template/175412/image_128/%5B106355%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20500?unique=381dd47)
|
Type number: 6.DD.630500 |
937.78 € | |
![[106356] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 600](/web/image/product.template/175413/image_128/%5B106356%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20600?unique=b93c60d)
|
Type number: 6.DD.630600 |
969.65 € | |
![[106357] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 700](/web/image/product.template/175414/image_128/%5B106357%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20700?unique=560a2ea)
|
Type number: 6.DD.630700 |
1,004.59 € | |
![[106358] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 800](/web/image/product.template/175415/image_128/%5B106358%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20800?unique=a135ba9)
|
Type number: 6.DD.630800 |
1,053.95 € | |
![[106359] RIEGLER Piston rod-free cylinder, double-acting, Piston Ø 63, Stroke 900](/web/image/product.template/175416/image_128/%5B106359%5D%20RIEGLER%20Piston%20rod-free%20cylinder%2C%20double-acting%2C%20Piston%20%C3%98%2063%2C%20Stroke%20900?unique=34f9b08)
|
Type number: 6.DD.630900 |
1,089.40 € | |
Accessoires and suitable extensions
| Product | Price | ||
|---|---|---|---|
![[106367] RIEGLER Foot fastening, for piston rod-free cylinder, Piston Ø 40](/web/image/product.template/175424/image_128/%5B106367%5D%20RIEGLER%20Foot%20fastening%2C%20for%20piston%20rod-free%20cylinder%2C%20Piston%20%C3%98%2040?unique=47043ca)
|
Type number: 455.14-M |
43.64 € | |
![[106372] RIEGLER Intermediate supports, for piston rod-free cylinder, Piston Ø 40](/web/image/product.template/175429/image_128/%5B106372%5D%20RIEGLER%20Intermediate%20supports%2C%20for%20piston%20rod-free%20cylinder%2C%20Piston%20%C3%98%2040?unique=3b4985d)
|
Type number: 455.54-M |
45.74 € | |
![[106376] RIEGLER Pivoting load fixture for piston rod-free cylinder, PistonØ 32-40](/web/image/product.template/175433/image_128/%5B106376%5D%20RIEGLER%20Pivoting%20load%20fixture%20for%20piston%20rod-free%20cylinder%2C%20Piston%C3%98%2032-40?unique=a452d65)
|
Type number: 455.23-M |
131.16 € | |
![[106381] RIEGLER Adjustable end position for piston rod-free cylinder, Piston Ø 40](/web/image/product.template/175438/image_128/%5B106381%5D%20RIEGLER%20Adjustable%20end%20position%20for%20piston%20rod-free%20cylinder%2C%20Piston%20%C3%98%2040?unique=2966e21)
|
Type number: 455.34-M |
478.48 € | |
![[106384] RIEGLER Cover belts for the T-slot, Piston Ø 32-125/32-63](/web/image/product.template/175441/image_128/%5B106384%5D%20RIEGLER%20Cover%20belts%20for%20the%20T-slot%2C%20Piston%20%C3%98%2032-125-32-63?unique=1389d6b)
|
Type number: 455.06-M |
4.24 € | |
![[194356] RIEGLER REED sensor for T-slots and rectangular slots,2-wire, 2.5 m cable](/web/image/product.template/216648/image_128/%5B194356%5D%20RIEGLER%20REED%20sensor%20for%20T-slots%20and%20rectangular%20slots%2C2-wire%2C%202.5%20m%20cable?unique=4a1136e)
|
Typennummer: 235.03-M-1 |
20.19 € | |
![[194357] RIEGLER REED sensor for T-slots and rectangular slots, 2-wire, M8, 300mm](/web/image/product.template/216649/image_128/%5B194357%5D%20RIEGLER%20REED%20sensor%20for%20T-slots%20and%20rectangular%20slots%2C%202-wire%2C%20M8%2C%20300mm?unique=29f390d)
|
Typennummer: 235.04-M-1 |
28.68 € | |
![[194358] RIEGLER HALL sensor for T-slots and rectangular slots,3-wire, 2.5 m cable](/web/image/product.template/216650/image_128/%5B194358%5D%20RIEGLER%20HALL%20sensor%20for%20T-slots%20and%20rectangular%20slots%2C3-wire%2C%202.5%20m%20cable?unique=cc7666f)
|
Typennummer: 235.06-M-1 |
27.41 € | |
![[194359] RIEGLER HALL sensor for T-slots and rectangular slots, 3-wire, M8, 300mm](/web/image/product.template/216651/image_128/%5B194359%5D%20RIEGLER%20HALL%20sensor%20for%20T-slots%20and%20rectangular%20slots%2C%203-wire%2C%20M8%2C%20300mm?unique=8fd5430)
|
Typennummer: 235.07-M-1 |
36.66 € | |
