RIEGLER Pressure switch, Polycarbonate, Plug M8, 4-pole, G 1/8 ET, M5 IT
Type number: VS 56
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Pressure switch made of polycarbonate, for vacuum technology - type VS 56
The RIEGLER pressure switch, plug M8, 4-pin, G 1/8 AG, M5 IG, M8x1 AG generates or uses vacuum for handling and automation tasks. The housing is made of polycarbonate. The temperature range is between 0 °C and 50 °C. Suitable for non-aggressive gases and dry, oil-free air. Operating voltage 10.8 - 30 V DC. Reliable vacuum technology.
Field of application
Typical areas of application: Robotics and packaging technology.
| Temperature range min. | 0 °C |
| Temperature range max. | 50 °C |
| Medium | non-aggressive gases and dry, oil-free air |
| Housing | Polycarbonates |
| Electrical connection | M8 plug, 4-pin |
| Operating voltage | 10.8 - 30 V DC |
| Hysteresis | adjustable: 0 - 100 % of the set value or comparator mode |
| Output signal | 2 digital |
| Switching capacity | 180 mA |
| Status display | 2 x LED |
| Measuring medium connection | G 1/8 AG and M5 IG |
| Power consumption | 55 mA |
| Measured value display | 3-digit 7-segment LED |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 10 |
| Type of construction | switching against + |
| L | 58.5 mm |
| L1 | 75.5 mm |
| G 1 | G 1/8 AG |
| G 2 | M5 IG |
| G 3 | M8x1 AG |
| Class name | PLUS |
