RIEGLER L screw-in fitting,R 3/8 o., for hose 8/6 mm, nickel-plated brass
Type number: 15.138-8
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER L-screw-in fitting made of nickel-plated brass, for pneumatic installation, max. 18 bar - Type 15.138-8
The RIEGLER L-screw-in fitting, R 3/8 a., for hose 8/6, MS nickel-plated connects compressed air hoses and pipes quickly and securely by simply screwing them in. The housing is made of nickel-plated brass. Designed for a maximum operating pressure of 18 bar. The operating temperature is between -20 °C and 300 °C. Connection thread R 3/8 - suitable for common industry standards. Simple assembly and disassembly for flexible pipe routing.
Field of application
Typical areas of application: Compressed air installations and pneumatic systems.
| Working pressure max. | 18 bar |
| Material | Nickel-plated brass |
| Operating temperature min. | -20 °C |
| Operating temperature max. | 300 °C |
| Thread | R 3/8 |
| SW | 12 mm |
| for hose | 8/6 mm |
| L1 | 23 mm |
| L2 | 45 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
| O-ring | without |
| Class name | EASY |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[110634] RIEGLER L screw-in fitting,R 1/2 o., for hose 10/8, nickel-plated brass](/web/image/product.template/181564/image_128/%5B110634%5D%20RIEGLER%20L%20screw-in%20fitting%2CR%201-2%20o.%2C%20for%20hose%2010-8%2C%20nickel-plated%20brass?unique=c42e9b3)
|
Type number: 15.112-10 |
6.06 € | |
![[110635] RIEGLER L screw-in fitting,R 1/2 o., for hose 12/10, nickel-plated brass](/web/image/product.template/181565/image_128/%5B110635%5D%20RIEGLER%20L%20screw-in%20fitting%2CR%201-2%20o.%2C%20for%20hose%2012-10%2C%20nickel-plated%20brass?unique=2d11d70)
|
Type number: 15.112-12 |
7.14 € | |
![[110630] RIEGLER L screw-in fitting,R 1/4 o., for hose 10/8, nickel-plated brass](/web/image/product.template/181560/image_128/%5B110630%5D%20RIEGLER%20L%20screw-in%20fitting%2CR%201-4%20o.%2C%20for%20hose%2010-8%2C%20nickel-plated%20brass?unique=6b03bdb)
|
Type number: 15.114-10 |
3.14 € | |
![[110628] RIEGLER L screw-in fitting,R 1/4 o., for hose 6/4 mm, nickel-plated brass](/web/image/product.template/181558/image_128/%5B110628%5D%20RIEGLER%20L%20screw-in%20fitting%2CR%201-4%20o.%2C%20for%20hose%206-4%20mm%2C%20nickel-plated%20brass?unique=23bcf94)
|
Type number: 15.114-6 |
2.44 € | |
![[110629] RIEGLER L screw-in fitting,R 1/4 o., for hose 8/6 mm, nickel-plated brass](/web/image/product.template/181559/image_128/%5B110629%5D%20RIEGLER%20L%20screw-in%20fitting%2CR%201-4%20o.%2C%20for%20hose%208-6%20mm%2C%20nickel-plated%20brass?unique=466a3f6)
|
Type number: 15.114-8 |
2.51 € | |
![[110625] RIEGLER L screw-in fitting,R 1/8 o., for hose 5/3 mm, nickel-plated brass](/web/image/product.template/181555/image_128/%5B110625%5D%20RIEGLER%20L%20screw-in%20fitting%2CR%201-8%20o.%2C%20for%20hose%205-3%20mm%2C%20nickel-plated%20brass?unique=de49251)
|
Type number: 15.118-5 |
2.37 € | |
![[110626] RIEGLER L screw-in fitting,R 1/8 o., for hose 6/4 mm, nickel-plated brass](/web/image/product.template/181556/image_128/%5B110626%5D%20RIEGLER%20L%20screw-in%20fitting%2CR%201-8%20o.%2C%20for%20hose%206-4%20mm%2C%20nickel-plated%20brass?unique=cb736fa)
|
