RIEGLER Round cylinder »MI«, double-acting, PistonØ 40, Stroke 500, G 1/4

Price:

115.94 €

RIEGLER Round cylinder »MI«, double-acting, PistonØ 40, Stroke 450, G 1/4
RIEGLER Round cylinder »MI«, double-acting, PistonØ 40, Stroke 450, G 1/4
110.09 € 110.09 €
RIEGLER Round cylinder »MI«, double-acting, Piston Ø 40, Stroke 50, G 1/4
RIEGLER Round cylinder »MI«, double-acting, Piston Ø 40, Stroke 50, G 1/4
69.29 € 69.29 €

RIEGLER Round cylinder »MI«, double-acting, PistonØ 40, Stroke 500, G 1/4

https://www.filcom-technik.de/web/image/product.template/198495/image_1920?unique=bb31667

Type number: 11.DM.40500

EAN: 4047322315197

115.94 € 115.94 EUR 115.94 € VAT Included

162.38 € VAT Included


  • Brand

This combination does not exist.

from 110 € free shipping Details shipping costs

Riegler

Riegler

RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.


Product no. :

114925

EAN :

4047322315197

Category :

Round Cylinders

Weight :

2.15 kg

Round cylinder "MI", double-acting, solenoid, piston Ø 40, stroke 500, connection G 1/4, working pressure 1 - 10 bar, temp. -20 °C to 70 °C

Temperature range min. -20 °C
Temperature range max. 70 °C
Sealing material NBR
Series Series MI
Working pressure min. 1 bar
Working pressure max. 10 bar
Pipe Stainless steel 1.4301
Type Type CM
Piston Ø 40 mm
Function double-acting
Stroke 500 mm
Piston rods AG M12x1.25
Piston rod Ø 16 mm
REACH SVHC1 Substance Name Lead
CAS No. SVHC 1 7439-92-1
Connection G 1/4
Piston rod Stainless steel 1.4301
Piston Aluminum
RoHS material information RoHS compliant
RoHS Directive 2011/65/EU, 2015/863/EU, 2018/741/EU
RoHS Article of the Directive Article 4, paragraph 1, Annex 3
Share of SVHC substance in % for RoHS 0.04
Exception 6c
REACH Info contains SVHC substance
Share of SVHC SCIP >= 1.0% w/w and < 10.0% w/w
Proportion of SVHC substance in SCIP >= 0.1 % in w/w
Class name EASY
Magnet with magnet
Damping without adjustable damping
Thread piston rod External thread on the piston rod
