RIEGLER Glycerine pressure gauge, CrNi steel, G 1/4, 0 - 4 bar, Ø 63
Type number: 4182
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Product no. :
134025EAN :
4047322483940Category :
Glycerine-Filled Pressure GaugesWeight :
0.28 kgGlycerine pressure gauge, stainless steel, single scale in bar, centric rear connection, G 1/4, grade 1.6, measuring range 0 - 4.0 bar, Ø 63
| Medium temperature min. | -20 °C |
| Medium temperature max. | 100 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Material | CrNi steel |
| Type | 233.50 |
| Viewing window | Polycarbonate |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 4 |
| Diameter | 63 mm |
| Graduation value in the bar range | 0.2 bar |
| Connection | G 1/4 |
| Quality class | 45444 |
| Lower / Upper measuring range limit | Overpressure |
| Connection position | rear, centric |
| Class name | STAINLESS STEEL |
| Process connection material | CrNi steel |
