RIEGLER SYNTESI" pressure switch, BG 2, G 3/8, 2 m cable

Type number: 5623S103

88.14 € 88.14 EUR 88.14 € VAT Included

102.87 € VAT Included

Brand

This combination does not exist.

Add to Cart

from 110 € free shipping Details shipping costs

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

144955

EAN :

4047322764346

Category :

System Extensions

Weight :

0.44 kg

Description
Specifications

Pressure switch "SYNTESI", BG 2, G 3/8, 2 m cable, setting range = 0.5 ? 10 bar, p1 = max. 13 bar, T = -10 ? 50°C

Inlet pressure max.	13 bar
Temperature range min.	-10 °C
Temperature range max.	50 °C
Medium	Compressed air or other neutral gases
Housing	Technopolymer
Setting range min.	0.5 bar
BG	2
Input connection	G 3/8
Output connection
A	60.5 mm
B	101 mm
Setting range max.	10 bar
Class name	PLUS
Voltage max.	250 V
Hysteresis min. (not adjustable)	0.4 bar
Hysteresis max. (not adjustable)	0.8 bar
Series	Syntesi
Protection class	IP65
Electrical connection	2m cable
Function	Changer
max. load	0.08333333333333326
F	32.5 mm

Accessoires and suitable extensions

	Price
[145559] RIEGLER Adjustment protection cap for pressure switches and soft start valves Type number: 9200703	3.09 €	Add to cart
[145659] RIEGLER SYNTESI" mounting bracket, BG 2, standard and anti-corrosion Type number: 9200717X	15.47 €	Add to cart
[145660] RIEGLER Adapter for DIN rail "SYNTESI", BG 1 and BG 2 Type number: 9200718X	18.99 €	Add to cart

Maintenance, wear and spare parts

Product		Price
	[144691] RIEGLER Threaded connection socket "SYNTESI", BG 2, G 3/8, incl. 2 screws Type number: 9210011	5.77 €	Add to cart
