RIEGLER 3/2-way valve, electropneumatic, bistable, G 1/4

https://www.filcom-technik.de/web/image/product.template/279327/image_1920?unique=70a2b2c

Type number: 7020020100

90.74 € 90.74 EUR 90.74 € VAT Included

105.90 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

145700

EAN :

4047322771719

Category :

Valves Electropneumatically Operated

Weight :

0.19 kg

3/2-way valve, electropneumatic, bistable, G 1/4, p = 1 ? 10 bar, T = -10 ? 60 °C, aluminum, without plug/coil

Medium Filtered compressed air with or without lubrication. If lubricated, then continuous.
Sealing material NBR
Series Valves Series 70
Operating pressure min. 1 bar
Max. operating pressure 10 bar
Medium temperature min. -10 °C
Medium temperature max. 60 °C
Ambient temperature min. -10 °C
Ambient temperature max. 60 °C
Manual override resting
DN 45419
Actuation bistable
Symbol 34
Connection G 1/4
Flow 1 750 Nl/min
Flow 2 1100 Nl/min
Class name PLUS
Function 45325
Flow rate measurement 1 Flow rate at 6 bar and ∆p 0.5 bar
Flow rate measurement 2 Flow rate at 6 bar and Δp 1.0 bar
